Concrete Testing Equipment

Optical Sensor

Optical Sensor Optical Sensor, for up to 3 feet. Range from 1 to 250,000 rpm

Tile Abrasion Tester

Tile Abrasion Tester: MTCT-124 The tile sample is pressed under a specified load against a grinding path strewn evenly with an abrasive powder revolving at the rate of 30 + 1 r.p.m. At the end of 100 revolutions of the disc the second parallel side of the tile is subjected to wear for an equal number of revolutions of the disc. The wear of tile is measured using a thickness gauge. The Abrasion testing machine consists of a replaceable grinding path fitting on to a disc rotating its vertical axis. The rotating disc and grinding path are enclosed by a circular tray. A bracket holds the specimen. The loading is by a counter balanced lever. A funnel is provided to facilitate charging the grinding path with abrasive powder. Supplied complete with automatic preset revolution counter and one weight but without abrasive powder and thickness gauge. Suitable for operation 230 V, single phase, Ac supply. TECHNICAL SPECIFICATION Abrasive powder revolving at the rate of 30 + 1 r.p.m. Operation 230 V, single phase, Ac supply. This counter is re-adjustable. The machine works on 440 volts A. C. Three phase electrical supply. A funnel is fitted to evenly spread abrasive powder on the grinding path. A counter balance lever loads the specimen. Load applied is 30 kgf. A pre-set counter automatically stops the machine after 22 revolutions.

Point Load Index Tester

Point Load Index Tester MTCT-122 Used for testing rock, aggregate and core samples as out crop specimen in their original shape very useful for rock classifications. This is a portable instrument and is useful in the field also uniaxial Compressive Strength for rock specimen can also be predicted approximately. The instrument comprises of a three pillar type load frame on the base of which at the center is fixed a 10 Tonne capacity hydraulic jack with a conical platen at the top of jack. The other conical platen is fixed to the top plate of the frame at its centre. The distance between two conical platen is fixed to the top plate of the frame at its center. The distance between two conical platens is adjustable by vertical movement of the upper plate of the load frame. Loading Jack with integral hand operated pump and two Pressure Gauges having graduations of 0-2500 kg x 25 kg and 0-10000Kg x 50Kg. TECHNICAL SPECIFICATION Display Analog Material for Construction Stainless steel Power Electric

Lateral Extensometer

Lateral Extensometer: MTCT-119 The unit consists of two movable frames pivoted at one end. The extensometer is fixed to the specimen with the help of tightening screws. The lateral extension is indicated on a dial gauge which is mounted on the upper ring and the tip of the dial gauge rests on an anvil. The zero on the dial gauge can be set by adjusting the anvil screw. TECHNICAL SPECIFICATION The unit consists of two movable frames pivoted at one end. The extensometer is fixed to the specimen with the help of tightening screws. The lateral extension is indicated on a dial gauge of 0.002mm x 12mm travel. The extension is magnified 2.5 times and the dial gauge readings are to be divided by 2.5 to get the exact readings. A spacer strip is provided to initially set the dial gauge, and can be removed after initial setting. Supplied in a wooden carrying case. The lateral extensions of 15cms dia x 30cm high cement concrete Cylinders while testing them under compression.

V Funnel Apparatus

V-Funnel Apparatus: MTCT-12 V box Bucket capacity of 14 liters Measuring scale 0 to 600 mm Sprit level Stop watch with accuracy of 0.1SEC.

J-Ring Apparatus

J-Ring Apparatus: MTCT-118 J-ring test the passing ability of the concrete .The equipment consists of rectangular section of 38 mm X 25 mm open steel ring drilled vertically with holes to accept threaded section of reinforcing bars 12 mm diameter 100 mm in length. The bars and sections can be placed at different distance apart to simulate the congestion of reinforcement of the ring formed by vertical section is 300 mm and height 100 mm. TECHNICAL SPECIFICATION Consists of rectangular section of 38 mm X 25 mm open steel ring drilled vertically with holes to accept threaded section of reinforcing bars 12 mm diameter 100 mm in length. The bars and sections can be placed at different distance apart to simulate the congestion of reinforcement of the ring formed by vertical section is 300 mm and height 100 mm

Hydraulic Jack

Hydraulic Jack Hydraulic Jacks are of multipurpose utility i.e. application of loads while engaged in field investigation, determination of load carrying capacity of piles in the field, tensioning of wires in pre-cast structures, loading of members of any structures for deformation characteristics for applying loads for various test in field or laboratory. Hydraulic Jack hand operated with separate pumping units. These jacks are portable available in various capacities. The pumping unit is connected to the hydraulic jack by means of a flexible connecting pipe 2 meter long. The jack is fitted with lifting handles for easy transportation. The approximate lift of the ram is 90 to 120 mm. The pumping unit is a single plunger type with detachable handle. The unit is fixed on a channeled base which is fitted with lifting handles. A pressure release valve is provided on the pumping unit. The load is indicated on a 15 cm dial hydraulic pressure gauge of appropriate capacity which can be detached from the pump when not in use. The least count of the calibrated dial will be according to the capacity of the gauge (Normally 100 divisions for full capacity). Lift of ram 150 mm. Technical Specification: Capacity: 10 Tonne, 20 Tonne, 25, Tonne, 50 Tonne, 100 Tonne, 150 Tonne and 200 Tonne. Material Stainless Steel Operating Mode Manual Piston travel 50 mm

Coarse Series

Compressometer Concrete Specimen

Specification of Compressometer Concrete Specimen 5 cm dla, 30 cm high may be evaluated for deformation and strain characteristics while undergoing compression testing.

Concrete Mixer

Concrete Mixer multi flow mixer absorbs fewer air during mixing, requires shorter mixing time and grants a perfect homogeneity in mixtures having a low water and cement ratio. The pan is easily removable by means of a trolley. The blades are hardened against wear.

Universal Force Table

Specific Gravity Density Apparatus

Compression Testing Machine

Concrete Test Hammer

Concrete Test Hammer: MTCT-110 Concrete structures will need to be examined and tested to ensure the concrete remains of adequate strength and durability. Rebound hammer surveys can be conducted to provide a rough estimate of concrete strength, where it is not possible to determine this by more accurate means such as core extraction and testing. The test involves using a special rebound hammer, which measures the recoil of a piston against the concrete surface when a standard force is applied. This recoil can then be correlated approximately to concrete strength. SPECIFICATION The rebound hammer consists of a barrel in which is housed a hammer mass attached to an impact spring which slides on a guide bar. A plunger is attached to the guide bar which is pressed against the surface to be tested. As the piston is pressed against the surface to be tested, on reaching the compressive strength, the hammer mass is released and rebounds to a certain extent, according to the strength of the surface, which is indicated by a rider on a calibrated scale. A lock button fixed on the body of the hammer lock the rider in place and the rider can be reset to zero Position by using the same button. The equivalent compressive strength can be computed from the chart supplied. It is suitable for specimen of compressive strengths 100-700Kg/cm. The instrument, complete with a grinding stone for polishing the test surface.

Concrete Permeability Apparatus

Concrete Permeability Apparatus: MTCT-109 A concrete structure is considered to be of adequate durability if it performs in accordance with its intended level of functionality and serviceability over an expected or predicted life cycle. Concrete durability depends largely on the ease (or difficulty) with which fluids (water, carbon dioxide, oxygen) in the form of liquid or gas can migrate through the hardened concrete mass. Concrete is a porous material. Therefore, moisture movement can occur by flow, diffusion, or sorption. We are concerned with all three, but generally the overall potential for moisture in concrete by these three modes is referred to as its permeability. TECHNICAL SPECIFICATION The set up consist of permeability cell, water reservoir and pressure lines, with glass bottles. Consists of a metal cylinder with a ledge at the bottom for retaining the specimen, a flange at the top, removable cover plate and a funnel. A rubber gasket is seated in matching grooves, between the cell and the cover plate, to render the joint water tight. Internal working size of the cell will be 100mm dia X 100mm hight. Consists of a length of metal pipe, 50 to 100 mm in diameter and about 500 mm long. The reservoir fitted with a graduated side arm gauge-glass for admitting water and compressed air and a cock for drainage, bleeding and connection to the permeability cell. Heavy duty armored rubber hose with end fittings. Complete with glass bottles but without compressor.

Compression Testing Machine

Permeability Apparatus

Permeability Apparatus Three Cell Model : Same as ECTM-43 but supplied with three individual cells with stand. Three pressure gauges for indicating pressure in each cell are supplied apart from the main pressure gauge which indicates pressure chamber.

Compression Testing Machine

Planter Apparatus

Beam Mould

Laboratory Pan Mixer

Laboratory Pan Mixer 56 LTS (Motorised): This muliflow mixer absorbs fewer air during mixing, requires shorter mixing time and grants a perfect homogeneity in mixtures having a low water and cement ratio. The pan is easily removable by means of a trolley. The blades are hardened against wear.

Tamping Bar

Teknik Extensometer

Extensometer: MTCT-114 Civil Engineering Concrete Testing Extensometer The unit consists of two movable frames pivoted at one end. The lateral extensometer is fixed to the specimen with the help of tightening screws. The lateral extension is indicated on a dial gauge of 0.002 mm x 12 mm travel. The extension is magnified 2.5 times and the dial gauge readings are to be divided by 2.5 to get the exact readings. A spacer strip is provided to initially set the dial gauge and can be removed after initial setting.

Cylindrical Mould

Cylindrical Moulds: MTCT-113 Cylindrical Mould that finds a major application in testing the compressive strength of concrete cylinders easy to assemble and disassemble, the proffered selection is offered in different specifications to meet the diverse client demands. The range is applauded for its sturdiness, corrosion resistance and longer operational life. TECHNICAL SPECIFICATION The mould is split vertically into two parts. The mean internal diameter in within +/-0.2mm and height is within +/-1mm. The ends are machined to +/-0.05. The base plate and top plate are machined flat to +/-0.03mm. Material for Construction Stainless steel

Demountable Mechanical Strain Gauge

Micro Controller Based Compression Testing Machine

Melting Pot

Capping Set Vertical

Sand Apsorption Cone and Tamper

Density of Fresh and Hardened Concrete

Vibrating Table

Curing Tank

Cube Mould

Mortar Penetrometer

Tamping Rod

Capping Set

Gang Mould

Longitudinal Compressometer

Longitudinal Compressometer: MTCT-120 It is designed for finding out the deformation and strains on cement and concrete cylinders when subjected to compressive loads. TECHNICAL SPECIFICATION Consists of a frame with a bottom ring and a top ring with tightening screws to firmly clamp the compress meter over the cylinder. A dial gauge 0.002mm x 12mm is mounted on the upper ring and the tip of the dial gauge rests on an anvil. The zero on the dial gauge can be set by adjusting the anvil screw. For 150mm dia x 300mm high specimen. Spacer holds the two frames in position. A pivot rod rests on pivot screws. A dial gauge, fixed to a bracket fitted to the top frame is used for taking deformation measurement. Supplied complete with dial gauge 0.002mm x 5mm in a nice wooden carrying case. ** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK keeps the right to modify the content in the product without prior notice.

Straight Edge

Accelerated Curing Tank

Accelerated Curing Tank Accelerated Curing tank shall be constructed from any material of suitable strength that will resist the effect of corrosion. Internal dimension should be adequate to accommodate the required number and size of test specimen. The tank shall contain sufficient water and be controlled so that temperature of water around the specimen immersed in the tank is maintained at the desired level. EXPERIMENTAL PROGRAM-To get the early age strength through accelerated curing, warm water method was adopted. In this method, after the casting of cubes, specimen was cured at normal temperature for 24 hours and then put in accelerated tank on second day with temperature 80 for 5 hours and then 80c to falling temperature up to next day. After this period of curing, concrete cube specimen was tested for compressive strength and results are co-related with 28 and 56 days compressive strength of standard water curing. This co relation of accelerated strength and normal curing strength is achieved for all types of cement. To find the confident level of these relation seven different types of cement were used. The composition of different types of Cement is given in table IV. For each type of cement four different were used. Mix design was prepared by ACI method. Technical Specification Voltage 220 V/440 V Driven Type Electric Frequency 50 Hz Power supply: 220-240V 1ph 50/60 Hz 4500W Temperature range from ambient to 100oC The separate control panel is provided with a thermoregulatory, timer, pilot lights, main switch The test consists essentially in curing the concrete specimens with water heated by 3 electric elements of 1500W each In side all from stainless steel, outside from steel painted sheet with an intermediate layer of insulating mineral wool. Temperature controller cum indicator Water circulation pump Calibration certificate is provided for digital controller

KELLEY Ball Penetration Apparatus

Laboratory Concrete Mixer

Laboratory Concrete Mixer (Motorised): Microteknik Manufacturer company in Concrete and mortar mixer for light professional and DIY use. Designed to give reliable service with low maintenance requirements. The compact storage size makes the Mixer a convenient product for DIY users. Advantages: Compact enough to be transported in the boot of car Supplied complete with stand Direct drive for increased reliability

Compression Testing Machine Hand Operated

Compression Testing Machine Hand Operated: This machine is quite useful on field Laboratories or mobile testing laboratories or Vans which frequently change site or location. It is particularly useful where constant and consistent Electric power is not available. The load is applied manually and observed on a Pressure gauge. The Pressure Gauge has maximum load indicator which stand still even after the specimen under test crushes and has to be set to zero manually. Salient Features: High Stability Self-aligning platen assembly. Gauges are calibrated in Kilo Newton against certified Proving Ring. Suitable for testing cubes of various sizes Using special platens, bricks also can be tested. Hard chrome plated piston with new type of long life oil seal. Four Pillar Model - superior in design, reliability and accuracy Practically no welded parts, all joints reinforced with heavy nut/bolt to withstand occasional over loading and to ensure center loading. Rounded Corners " add to elegance and safeguard against injury Hardened and grinded platens with guide lines for placing sample for Testing Optional Accessories (at extra cost) Spare Oil Seal Brick Testing Attachment Hydraulic Oil (Tin of 5 Liters)

Pocket Concrete Penetrometer

Concrete Penetrometer MTCT-108 This test is used to determine the elapsed time between batching of a concrete sample and when it is deemed by standard methods to have set. The method involves measuring the penetration resistance of a test sample, which has had coarse particles removed at periodic intervals. It is particularly useful, in determining the effect on setting time of admixtures in the concrete, where these may have been introduced specifically to increase the setting time. It consists of cylindrical spring housing with a plunger attached to the top of the spring. Penetration needle is attached to the other end of the spring housing. The plunger is graduated in 1 kg divisions, to a maximum capacity of 60kg, which can be read with respect to the top end of the spring housing. A set of six needle points with areas of 645, 323, 161, 65, 32 and 16mm2 are provided. Specification of Concrete Penetrometer Consists of a needle having face area 3/10 sq.cm. And graduated at a distance of 25mm. The needles point is an integral part of barrel which houses a calibrated spring. The spring is confined in a sleeve. The resistance offered by the concrete mortar is shown on the direct reading scale with a marker ring which holds its position when released. Scale range is 0-50 kg/cm2 when the penetration resistance reaches a value of 35kg/cm2 the concrete is assumed initially set.

Kelley Ball Penetration

VEE BEE Consistometer

Cube Mould with Base Plate

Automatic Compression Testing Machine

Fully Automatic Concrete Cube Compression Testing Machine: MTCT-105 The automatic range of 3000 kN capacity compression testing machines has been designed to meet the need for reliable and consistent testing of concrete samples all lab test machines feature the complete automatic test cycle with a closed loop digital readout. Once the specimen parameters have been introduced, it is sufficient to press the start button to complete the test. Lab test compression machines consist of their main parts: frame, power pack and data acquisition control system. Each part has been designed to manufacture machines with a high degree of mechanical. TECHNICAL SPECIFICATION Capacity (KN) 500 Platen Dia (mm) Dia 200 Ram travel (mm) 50 Vertical daylight (mm) 230 Horizontal daylight (mm) 230 Automatic test cycle with standard rapid approach Graphical " LCD data acquisition and control system Menu driven software for easy operation Load vs time plot and instantaneous load rate displayed Accurate load rate control within ±5 from 1 kN/sec to 20 kN /sec Class 1 starting from % 10 of the full range Set test parameters " including load rate and Press the start button The machine automatically starts the rapid approach; switches to the test speed once the specimen comes into contact with the upper platen; automatically release the pressure upon specimen failure Save the test including data results and load-time graph (Optional) Dual stage pump assuring fast piston approach and precise test execution Controllable pace rate from 1 KN/Sec to 10 KN/Sec. Inbuilt graph in the touch screen display. Auto stop and auto release after completion of each test. Accuracy starting from 10% of full scale. Soft platen-to-specimen contact and smooth load rate control from the very beginning of the ramp Allow remote verification of settings and performances. Easy debugging of unexpected malfunctions. Complete IP based controller. Working on 240V, 50-60Hz, single phase.

Permeability Tests

Tile Flexural Testing Machine

Tile Flexural Testing Machine: MTCT-125 Flexural strength of clay roofing tiles cement concrete flooring tiles. Flexural load is applies on the tiles using lead shots. The machine consists of a stand on which two 40mm dia bearing rollers or 12mm dia rollers are placed at centre distance of 150mm, 200mm, 250mm, or 270mm as the case may be. The third upper roller applies centrally flexural load by means of lever arrangement. Lead shot contained in an upper vessel start flowing into lower container at a rate of 45 to 55 kg. Per minute or 200 kg per minute there by, starting loading the specimen. Arrangement is made such that loading automatically stops when specimen breaks. TECHNICAL SPECIFICATION The machine consists of a stand on which two 40mm dia bearing rollers or 12mm dia rollers are placed at centre distance of 150mm, 200mm, 250mm, or 270mm as the case may be. The third upper roller applies centrally flexural load by means of lever arrangement. Lead shot contained in an upper vessel start flowing into lower container at a rate of 45 to 55 kg. Per minute or 200 kg per minute there by, starting loading the specimen. Arrangement is made such that loading automatically stops when specimen breaks. Supplied without lead shots.

Concrete Slump Test Apparatus

Slump Test Apparatus: MTCT-123 The oldest most widely used test for determining workability. This test is used to determine the workability of fresh concrete, which would normally be undertaken at the point of delivery to ensure the concrete, is of adequate consistency for placement. The test is applicable to concrete of medium workability. The device is a hollow cone-shaped mould. The mold is filled in three layers of each volume. Each layer is rodded with a 16mm steel rod 25 times. The mould is then lifted away and the change in the height of the concrete is measured against the mould. The slump test is a measure of the resistance of concrete to flow under its own weight. TECHNICAL SPECIFICATION The apparatus comprise of a slump cone with handles made of mild steel sheet, a chrome plated steel tamping rod of 16 mm diameter X 600 mm long, rounded off at one end, with a scale marked on it and a steel base plate with a carrying handle. The mould for the test specimen will be in the form of frustum of a cone having the following internal dimensions as follows. Bottom diameter 20 cm Top diameter 10 cm The Cone is constructed of metal of at least 1.6 mm thickness and the top and bottom are open and at right angles to the axis of the cone. The mould have a smooth internal surface and provided with suitable foot pieces to a base plate and also handles to facilitate lifting it from the molded concrete test specimen in a vertical direction as required by the test. The base plate is provided with cleats & swivel handle.

Compaction Factor Apparatus

Compaction Factor Apparatus: MTCT-103 The compaction factor is defined as the ratio of the mass of the concrete compacted in the compaction factor apparatus to the mass of the fully compacted concrete. It involves dropping a volume of concrete from one hopper to another and measuring the volume of concrete in the final hopper to that of a fully compacted volume. The results of the compaction factor test can be correlated to slump, although the relationship is not linear. This test is difficult to run in the field and is not practical for large aggregates Compared to the slump test, the apparatus is bulky and a balance is required to perform measurements.

Moulds Cube

Cube Mould MTCT-112 Cubes of fresh concrete are made to test a variety of properties on the eventually cured and hardened concrete. Fresh concrete is subjected to a standard compaction regime in the cube mould and is then normally initially cured under specific laboratory conditions. The moulds are manufactured, subject to tight dimensional, hardness, square ness and surface finish requirements. SPECIFICATION Complete with base plate. The faces of the mould are machined flat to +/- 0.02mm accuracy and finished to within +/- 0.2mm of specified dimensions. Material for construction of moulds is Cast Iron or Mild steel. The moulds are stout enough to prevent distortion and facilitate the removal of the molded specimen without damage. The Moulds are so machined that when they are assembled ready for use, the dimensions and internal faces are accurate within the specified limits. Internal faces of the moulds are smooth. The base plate is attached to the mould by cleats The parts of the mould, when assembled, are positively and rigidly held together during filling, subsequent handling and vibration where applicable.

Needle Vibrator

Needle Vibrator: MTCT-121 In the process of compaction, efforts are only directed to reduce voids in the compacted concrete. The Vibrators produce vibrations which when transmitted to plastic concrete make it to flow and affect compaction. The air bubbles are forced out of concrete due to vibrations. The Needle Vibrator, also known as immersion or poker vibrator have a power unit and long flexible tube at the end of which a vibrating head is attached. Wherever compaction is to be done, the vibrating head is inserted in the concrete. TECHNICAL SPECIFICATION The Laboratory needle vibrator having 350mm long X 25mm dia Needle is used in vibrating concrete test cylinders and beams in the field or laboratory. It is also widely used in making laboratory specimens, in making concrete products, in experimental works, and in small scale construction project. It has 1 meter long flexible shaft and is powered by 1 HP single Phase Electric motor. The Needle vibrator for compaction of mass concrete has 40 or 60mm dia needle with 6 meter long flexible shaft and powered by 3 HP Electric motor for operation on 440 Volts, 3 phase, 50 cycles, A.C. Supply. Optionally, the Vibrator can also be fitted with Petrol/kerosene or Diesel Engine for field use.

Flexural Testing Machine

Flexural Testing Machine: MTCT-115 Although generally not such an important property of concrete than compressive strength, tensile strength values are often important to know when the concrete used free of reinforcement and may be subjected to some tensile force. The test method essentially involves applying a load at the centre of a beam of concrete supported at its ends. The load required to break the specimen is then recorded. TECHNICAL SPECIFICATION For 150 mm x 150 mm x 700 mm beam, the centre distance between the rollers is 600 mm, while it is 400 mm for beams of size 100 mm x 100 mm x 500 mm. It is 200 mm centre to centre, for 150 mm x 150 mm x 700 mm size beam and 133 mm for 100 mm x 100 mm x 500 mm size beam. Total capacity of the machine is 100 KN. 150mm dia pressure gauge of 0-100 KN x 1 KN least count to indicate load is fixed on the load frame. A separate electrically cum hand operated pumping unit housed in a cabinet is supplied. On/Off switch and a slow/fast lever to control rate of loading are fitted on the front panel of the pumping unit. OPTIONAL ACCESSORIES Spare Oil seal Hydraulic Oil ( tin of 5 liters) Beam Mould 10 X 10 X 50 cm Beam Mould 15 X 15 X 60 cm Beam Mould 15 X 15 X 70 cm Beam Mould 15 X 15 X 75 cm Trowel Concrete Scoop

Compression Testing Machine

Compression Testing Machine Channel Type MTCT-106 This machine is quite useful on field Laboratories or mobile testing laboratories or Vans which frequently change site or location. It is particularly useful where constant and consistent Electric power is not available. The load is applied manually and observed on a Pressure gauge. The Pressure Gauge has maximum load indicator which stand still even after the specimen under test crushes and has to be set to zero manually. Features of Compression Testing Machine High Stability Self-aligning platen assembly. Gauges are calibrated in Kilo Newton against certified Proving Ring. Suitable for testing cubes of various sizes Using special platens, bricks also can be tested. Hard chrome plated piston with new type of long life oil seal. Four Pillar Model " superior in design, reliability and accuracy Practically no welded parts, all joints reinforced with heavy nut/bolt to withstand occasional over loading and to ensure center loading. Rounded Corners " add to elegance and safeguard against injury Hardened and grinded platens with guide lines for placing sample for Testing

Digital Compression Testing Machine

Digital Compression Testing Machine: MTCT-104 The digital compression testing machine has been designed to meet the need for a simple, economic and reliable means to test concrete for its compressive strength. The design expressive of simplicity, both of construction and operation, makes the machine easy to use and maintain. The unit is compact, making it useful for site and Laboratory applications. The digital machines are provided with a pace rate controller, to enable maintain a constant of loading. TECHNICAL SPECIFICATION The Complete unit comprises a Loading Unit which is of fully welded or two pillar model construction having a cross-head with a spherical seated platen. The lower platen is attached to the top of the piston. The Loading capacity is of 2000 KN, Cubes up to 200 mm & Cylinders up to 150 mm Dia X 300 mm Height can be tested using the appropriate spacers. Pumping Unit with choice of compact power pack attached closely to the loading unit or separate hydraulic pumping unit, attached to the loading unit by high pressure hydraulic flexible hose pipe. The pump facilitates rapid approach of the platens for daylight closure and also provides comprehensive control over the application of load. A control valve provides fine control over the loading rate for accurate pacing. Maximum load is held and retained for approx. 15 min, unless cancelled, using the panel mounted reset switch. Pace rate set for running the test can be maintained manually. Type of Pumping Electrical Loading Range 2000KN Least Count 1 KN Max. Clearance Between Platen 370mm Max. Clearance Between Side Platen 340mm Platen Size 220 mm sq. Piston Stroke 215.00 mm
