Side Extensometer

Side Extensometer

Send Inquiry

Request To Call Back

Side Extensometer

Get a Price/Quote

MOQ : 1 Unit

Side Extensometer Specification

Number of Specimens
1

Usage
Concrete Testing Equipment

Accuracy
0.01 mm

Application
Concrete Testing Equipment

Product Type
Lateral Extensometer

Measuring Range
05 mm

Resolution
0.01 mm

Mounting Type
Mechanical clamp

Hardness
Case hardened steel contact points

Power Supply
Not required (operates mechanically)

Temperature
10C to 50C

Response Time
Instantaneous (mechanical)

Humidity
Up to 85% RH

Specimen Size
150 mm x 150 mm (standard cube)

Test Range
05 mm

Display Type
Dial Gauge

Equipment Type
Side Extensometer

Automation Grade
Manual

Features
Precision adjustment, robust mechanism, easy attachment

Capacity
05 mm displacement

Machine Weight
Approx. 1.5 kg

Test Speed
Manual

Test Width
Up to 150 mm

Test Stroke
10 mm

Control Mode
Mechanical

Gauge Length
100 mm

Finish
Powder coated

Attachment
Spring loading for secure grip

Suitable For
Compression and flexure tests

Frame Material
Aluminum casting

Contact Points Material
Hardened steel

Side Extensometer Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Middle East, Asia, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Side Extensometer

Lateral Extensometer: MTCT-119

The unit consists of two movable frames pivoted at one end. The extensometer is fixed to the specimen with the help of tightening screws. The lateral extension is indicated on a dial gauge which is mounted on the upper ring and the tip of the dial gauge rests on an anvil. The zero on the dial gauge can be set by adjusting the anvil screw.

TECHNICAL SPECIFICATION

The unit consists of two movable frames pivoted at one end.
The extensometer is fixed to the specimen with the help of tightening screws.
The lateral extension is indicated on a dial gauge of 0.002mm x 12mm travel.
The extension is magnified 2.5 times and the dial gauge readings are to be divided by 2.5 to get the exact readings.
A spacer strip is provided to initially set the dial gauge, and can be removed after initial setting.
Supplied in a wooden carrying case.
The lateral extensions of 15cms dia x 30cm high cement concrete
Cylinders while testing them under compression.

High Precision Measurement for Concrete Testing

The Side Extensometer offers highly accurate displacement readings with a resolution of 0.01 mm and instant mechanical response. Its ideal for evaluating the structural integrity and deformation characteristics of concrete cubes during compression and flexural assessments, ensuring reliable quality control for construction and research.

Durable and Effortless Operation

Constructed with case-hardened steel contact points and a sturdy aluminum cast frame, the extensometer withstands rigorous daily use and harsh laboratory conditions. The mechanical spring-loading attachment ensures quick installation and safe grip, making the setup easy and efficientperfect for busy testing environments.

Versatile and Reliable in Diverse Conditions

This extensometer performs flawlessly within temperature ranges from 10C to 50C and humidity up to 85% RH. Since its manually operated, theres no dependence on electrical supply. Its mechanical design makes it suitable for a wide range of concrete specimen sizes and testing standards, supporting quality control in both field and laboratory settings.

FAQs of Side Extensometer:

Q: How is the Side Extensometer attached to a concrete specimen?

A: The Side Extensometer is mounted using a spring-loaded mechanical clamp that provides a secure and stable grip on standard concrete cubes measuring up to 150 mm x 150 mm. This ensures proper positioning during compression or flexure tests.

Q: What are the benefits of using hardened steel contact points?

A: Hardened steel contact points offer high durability and wear resistance, ensuring consistent measurements over repeated use. The case hardening provides added longevity, especially when testing rough or hard concrete surfaces.

Q: When is the ideal time to use the Side Extensometer in concrete testing?

A: The device should be used during the compression or flexural testing of concrete specimens to measure lateral displacement. This helps determine deformation characteristics and guarantees the structural quality of the tested materials.

Q: Where can the Side Extensometer be used?

A: It is suitable for laboratory settings and on-site concrete testing environments such as construction sites, material testing labs, and research facilities. Its robust build and manual operation make it adaptable to varied operating conditions.

Q: What is the process for measuring with this extensometer?

A: To measure lateral displacement, simply clamp the extensometer onto the specimen, conduct the test manually, and observe readings directly from the dial gauge. The device measures displacements within a range of 05 mm with instant response.

Q: How does manual test speed affect accuracy or response time?

A: Manual operation of the extensometer does not compromise accuracy or response time. The mechanical design provides instantaneous readings with an accuracy of 0.01 mm, ensuring precise monitoring throughout the compression or flexure process.

Q: What advantages does this extensometer offer to distributors or suppliers in India?

A: Its ease of use, mechanical reliability, and adaptability to Indian environmental conditions make it a preferred choice for distributors, exporters, and manufacturers seeking rugged and precise concrete testing solutions.
