Concrete Test Hammer

Concrete Test Hammer

Send Inquiry

Request To Call Back

Concrete Test Hammer

Get a Price/Quote

MOQ : 1 Unit

Concrete Test Hammer Specification

Usage
Concrete Testing Equipment

Accuracy
2 MPa

Display Type
Analog Scale

Product Type
Concrete Test Hammer

Test Range
10 70 MPa

Hardness
Spring steel impact mechanism

Measuring Range
10 to 70 MPa

Mounting Type
Handheld

Interface Type
Analog (manual reading)

Humidity
85% RH

Resolution
1 MPa

Specimen Size
Surface area 150 x 150 mm

Frequency
Single impact

Temperature
0C to 40C

Number of Specimens
1 per test

Automation Grade
Manual

Max Height
180 mm

Response Time
Immediate

Application
Concrete Testing Equipment

Power Supply
Not required (mechanical operation)

Features
Durable body, easy grip, reliable readings

Equipment Type
Concrete Test Hammer

Capacity
2000 impacts

Machine Weight
1 kg

Test Speed
Standard impact rate

Test Width
35 mm

Test Stroke
75 mm

Control Mode
Manual

Body Material
Aluminum

Dimensions
Length 180 mm x Diameter 54 mm

Color
Silver

Impact Energy
2.207 Nm

Plunger Tip Material
Hardened steel

Rebound Value
20 - 60 (typical scale)

Portable
Yes

Calibration Method
Calibration block included

Concrete Test Hammer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Telegraphic Transfer (T/T), Cheque, Letter of Credit (L/C), Cash in Advance (CID)

Supply Ability
100 Units Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Concrete Test Hammer

Concrete Test Hammer: MTCT-110

Concrete structures will need to be examined and tested to ensure the concrete remains of adequate strength and durability. Rebound hammer surveys can be conducted to provide a rough estimate of concrete strength, where it is not possible to determine this by more accurate means such as core extraction and testing. The test involves using a special rebound hammer, which measures the recoil of a piston against the concrete surface when a standard force is applied. This recoil can then be correlated approximately to concrete strength.

SPECIFICATION

The rebound hammer consists of a barrel in which is housed a hammer mass attached to an impact spring which slides on a guide bar.
A plunger is attached to the guide bar which is pressed against the surface to be tested.
As the piston is pressed against the surface to be tested, on reaching the compressive strength, the hammer mass is released and rebounds to a certain extent, according to the strength of the surface, which is indicated by a rider on a calibrated scale.
A lock button fixed on the body of the hammer lock the rider in place and the rider can be reset to zero Position by using the same button.
The equivalent compressive strength can be computed from the chart supplied.
It is suitable for specimen of compressive strengths 100-700Kg/cm.
The instrument, complete with a grinding stone for polishing the test surface.

High-Precision Concrete Testing

Engineered for accuracy and durability, the Concrete Test Hammer is essential for on-site evaluations of concrete structures. Its impact energy of 2.207 Nm combined with a hardened steel plunger tip ensures consistent, repeatable results, making it ideal for contractors and quality inspectors who demand reliable performance.

User-Friendly and Efficient Operation

With its comfortable hand-held design and manual analog scale, the hammer is easy to operate even in challenging environments. Theres no need for batteries or external power, allowing for immediate use and easy maintenance. The device includes a calibration block and can test concrete surfaces as large as 150 x 150 mm, delivering fast, trustworthy readings.

FAQs of Concrete Test Hammer:

Q: How do I use the Concrete Test Hammer for checking concrete strength?

A: To use the hammer, firmly hold it against a clean, flat area of the concrete surface (minimum 150 x 150 mm), and press until the device triggers a single impact. Read the rebound value directly from the analog scale and reference it to determine the compressive strength, which ranges from 10 to 70 MPa.

Q: What is the recommended process for calibrating the test hammer?

A: Calibration is performed using the included calibration block. Place the hammer on the block, perform several test impacts as per manufacturer instructions, and ensure readings fall within the specified range (20 60 on the analog scale). If necessary, adjust the device according to the manual to maintain accuracy.

Q: When should I use this test hammer for my concrete projects?

A: Use the Concrete Test Hammer during site inspections, post-construction evaluations, or periodic quality checks. Its ideal when you need quick, non-destructive assessment of concrete strength without interrupting ongoing work or waiting for lab results.

Q: Where can this equipment be effectively used?

A: This hammer can be used on any concrete surface meeting the minimum required test area (150 x 150 mm), whether at construction sites, bridges, roads, factories, or precast concrete plants. Its portable, manual operation suits both indoor and outdoor applications across India.

Q: What are the main benefits of using this hammer?

A: Key benefits include immediate, accurate results; durable aluminum body for extended use; a user-friendly analog interface; and independence from external power sources. The hammers lightweight design facilitates easy transport and quick setup in various field conditions.

Q: How does the equipment ensure durability and reliable readings?

A: The hammer features a hardened steel plunger tip and a spring steel impact mechanism, ensuring resilience and consistent performance. The aluminum body is engineered for longevity, while the mechanical operation minimizes electronic failures, guaranteeing reproducible results over thousands of uses.
