Marshall Stability Test Machine

Marshall Stability Test Machine

Send Inquiry

Request To Call Back

Marshall Stability Test Machine

Get a Price/Quote

MOQ : 1 Piece

Marshall Stability Test Machine Specification

Product Type
Marshall Stability Test Apparatus

Port Size
Standard Specimen Holder Slot

Mounting Type
Bench-top

Accuracy
1%

Number of Specimens
1 per cycle

Frequency
50 Hz

Specimen Size
101.6 mm diameter, 63.5 mm height

Power Supply
220V AC, 50 Hz

Display Type
Digital / Analog

Features
High precision, rugged construction

Max Height
500 mm (with accessories)

Resolution
0.01 kN

Application
Bitumen Testing Instruments

Operating Voltage
220V AC

Test Range
0 50 kN

Humidity
Up to 85% RH (non-condensing)

Usage
Bitumen Testing Instruments

Measuring Range
0-50 kN

Equipment Type
Marshall Stability Test Machine

Response Time
Instantaneous

Interface Type
Panel / Digital Display

Temperature
Operating: 5 to 40C

Automation Grade
Semi-Automatic / Manual

Capacity
5000 kg (50 kN)

Machine Weight
Approx. 80-100 kg

Test Speed
50.8 mm/min (2 inches/min)

Test Width
Standard mold width (approx. 101.6 mm)

Test Stroke
0-100 mm

Control Mode
Manual / Automatic

Marshall Stability Test Machine Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Africa, Middle East, Asia

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Marshall Stability Test Machine

Marshall Stability Test Apparatus :

MARSHALL APPARATUS CONSISTS OF:
Robust Construction
50KN capacity
Rate of travel 50.8mm/min
Safety cut-off switch

It consists of body housing, a geared screw jack and motor drive mechanism suitable for operation on 230 V, 50Hz, Single Phase, A.C. supply.

Reliable Marshall Stability Testing

Our Marshall Stability Test Machine precisely evaluates the strength and stability of bituminous materials, essential for highway and road construction. Complying with ASTM D6927 and IS 1207 standards, it guarantees repeatable test results with an operating speed of 50.8 mm/min and a measuring accuracy of 1%. The machines peak load mode with automatic capture ensures optimal sample analysis, making it a trusted choice for diverse testing environments across India.

Sturdy Construction and User-Friendly Operation

Manufactured from mild steel with an anti-corrosion coating, the machine is built for longevity in harsh lab settings. It accommodates both manual and automatic operation, with bench-top mounting for efficient use. The easy-to-use hand wheel or motor-driven cradle allows precise specimen placement. With its digital display and intuitive control panel, users can effortlessly conduct tests while maintaining accurate records.

Versatile Application and Enhanced Safety

Designed for bitumen testing, the equipment supports laboratories, research institutes, and civil engineering projects. Its compatibility with standard-sized molds and specimens, along with its compact and stable design (approx. 80100 kg), ensures safe and steady testing. Operating safely within temperatures from 5C to 40C and up to 85% RH, the machine is built to perform accurately under varying conditions.

FAQs of Marshall Stability Test Machine:

Q: How does the Marshall Stability Test Machine measure specimen stability?

A: The machine uses a proving ring or load cell to measure load applied to the specimen. It features peak load mode with automatic capture, instantly displaying the maximum load at break on a digital or analog indicator for precise stability measurements.

Q: What are the main benefits of using this test machine for bitumen testing?

A: This Marshall Stability Test Machine offers high precision (1% accuracy), robust construction, user-friendly controls, and rapid response time. These ensure accurate, repeatable results while maximizing user safety and efficiency. Its instant digital capture of peak load minimizes manual error, improving laboratory productivity.

Q: When should I use the manual mode versus the automatic mode of operation?

A: Manual mode is suitable when hands-on control and precise adjustments are needed, especially for training or specific custom tests. Automatic mode is preferable for routine testing, as it streamlines the process and minimizes operator intervention, ensuring consistency across multiple tests.

Q: Where can the Marshall Stability Test Machine be installed?

A: The equipment is designed for bench-top mounting and is suitable for installation in laboratories, quality control rooms, research institutes, and educational settings involved in bitumen or asphalt testing. Its durable build and compact size accommodate various working environments.

Q: What is the testing process using this machine?

A: Place the cylindrical specimen (101.6 mm diameter, 63.5 mm height) in the machines standard holder slot. Lower the movable platen to position the sample, then initiate the test at 50.8 mm/min. The load is applied vertically until specimen failure, with the peak load automatically recorded for analysis.

Q: How many specimens can be tested per cycle, and what is the capacity?

A: The machine tests one specimen per cycle, adhering to standard test protocols. It supports a maximum load capacity of 5000 kg (50 kN) and a test stroke range of 0100 mm, accommodating typical laboratory needs.

Q: What are the usage advantages for laboratories in India?

A: With compliance to Indian and international standards (ASTM D6927, IS 1207), this machine delivers reliable performance for Indian laboratories and field sites. Its robust construction, low maintenance, and adaptability to local environmental conditions make it ideal for bitumen quality assurance and research applications.
