Blue colored Bitumen Extractor Hand Operated

Blue colored Bitumen Extractor Hand Operated

Send Inquiry

Request To Call Back

Blue colored Bitumen Extractor Hand Operated

Price 100 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Blue colored Bitumen Extractor Hand Operated Specification

Accuracy
High extraction accuracy (standard compliant)

Test Range
Applicable to bitumen and asphalt

Max Height
Approx 45 cm

Usage
Bitumen Testing Instruments

Number of Specimens
Single per extraction

Hardness
High mechanical strength body

Automation Grade
Manual

Humidity
Suitable for standard laboratory conditions

Power Supply
Not required (Hand Operated)

Interface Type
Mechanical Interface

Features
Durable cast iron construction, corrosion-resistant coating, robust mechanical drive, solvent-resistant vessel, removable sieve

Product Type
Bitumen Extractor Hand Operated

Resolution
Standard lab grade

Measuring Range
Up to 1500 g

Response Time
Immediate (manual process)

Temperature
Ambient lab temperature (0C to 50C)

Equipment Type
Bitumen Extractor Hand Operated

Mounting Type
Tabletop

Application
Bitumen Testing Instruments

Specimen Size
Up to 1500 g

Port Size
Standard Discharge Port

Display Type
Not Applicable (mechanical operation)

Capacity
1500 g (approx)

Machine Weight
Approx 12 kg

Test Speed
Manual (Hand Operated)

Test Width
Standard Suitable for Bitumen Testing (as per IS:2720)

Test Stroke
Full drum rotation

Control Mode
Mechanical / Hand Crank

Blue colored Bitumen Extractor Hand Operated Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Middle East, Africa, Asia

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Blue colored Bitumen Extractor Hand Operated

Bitumen Extractor, Hand operated :

Introduction

The Centrifuge Extractors are used for determination of bitumen percentage in hot mixed paving mixtures and pavement samples. The mix is added with a solvent and dissolved bitumen is removed by centrifugal action. The Extractors are available in two versions, Hand operated and motorised electrically driven.

General Description & Specifications
Hand driven
The Centrifuge Extractor comprises of a precision machine rotor bowl and bowl cover housed in a cylindrical aluminum box. A knurled nut is provided to press filter paper disc between the rotor bowl and cover plate and the complete bowl assembly is removable for determination of weight of sample. The bowl assembly is mounted on a vertical shaft, which comes out from a casted housing. The shaft attached to the bowl is rotated manually by a handle. The gears operate in a casted housing in oil bath with splash lubrication. A drain is provided to collect dissolved bitumen coming out from the rotating bowl. The range of speed is 2400 - 3600 RPM. The bowl capacity is 1.5 Liter

Motorised electrically driven

The motorised version is provided with a variable speed control device and a hand brake to stop rotation when switched off. The electric motor is of 0.25 HP capacity coupled to a geared assembly. Suitable for operation on 230 Volts, 50 Hz, AC single phase.

Recommended Accessories & Consumbles

The following accessories and consumables are not part of the standard supply and are mandatory for the testing work
Filter paper ( Pack of 100)
Electronic balance ( 5 kg/500mg or 5 kg/100mg or 5 kg/10mg)
Two Pan Balance of 5 kg capacity with weights.(From 5 kg to 500gm)
Analytical weight Box (from 200gm to 1 mg)
Transfer Tray
Spatula
Solvent (Benzene/Toluene)
Asbestos hand Gloves.

Robust and Chemical-Resistant Design

Engineered with a powder-coated blue body and a corrosion-resistant drum, this bitumen extractor is built for long-term durability in laboratory settings. Its stainless steel, solvent-resistant container ensures compatibility with aggressive chemicals used in extraction processes. The bodys robust cast iron construction provides high mechanical strength, supporting continuous usage without degradation.

Efficient Centrifugal Extraction

Operating through a hand crank and gear-driven mechanism, the device efficiently separates bitumen from asphalt mixtures via centrifugal force. The manual process gives users direct control over the speed and extraction time, ensuring compliance with standard lab protocols and maintaining high accuracy for bitumen analysis.

Versatile Laboratory Application

Suitable for bitumen testing as per IS:2720 standards, this hand-operated extractor accommodates up to 1500 g samples. Its controlled discharge valve and removable 1 mm sieve (with optional sizes) allow tailored extraction for various specimen types. With its manual operation, it requires no electrical supply, ideal for standard lab environments across India.

FAQs of Blue colored Bitumen Extractor Hand Operated:

Q: How does the hand-operated bitumen extractor work?

A: This bitumen extractor uses a manual centrifugal process. By turning the hand crank, the drum rotates, separating bitumen from the sample via centrifugal force. The extracted liquid is then drained through a discharge valve for safe and precise collection.

Q: What solvents are compatible with this extractor?

A: The unit is designed to work with trichloroethylene (TCE) or any suitable solvent necessary for bitumen extraction as per standard laboratory protocols, ensuring efficient dissolution and separation of bitumen from asphalt mixtures.

Q: When should the removable sieve be changed?

A: The standard fitted sieve is 1 mm mesh, suitable for most tests. However, if different particle sizes are required by specific protocols or sample characteristics, optional sieve sizes can be used. Replace the sieve as needed to maintain testing accuracy or accommodate alternate test methods.

Q: Where can this manual bitumen extractor be used?

A: This device is intended for laboratory environments and is well-suited to Indian labs conducting bitumen and asphalt testing. Its tabletop mounting and manual operation make it compatible with labs that do not require electrical-powered equipment.

Q: What is the recommended process for bitumen extraction using this device?

A: First, load a sample (up to 1500 g) into the drum with the appropriate solvent. Secure the lid, spin the hand crank to initiate centrifugal separation, and use the discharge valve to collect the solvent-bitumen mixture for further analysis. Regularly clean the device and sieve for optimum accuracy.

Q: Can this extractor handle large sample sizes?

A: Yes, it is designed to process a single specimen up to approximately 1500 g, making it suitable for standard laboratory bitumen extraction tests as required by recognized standards.

Q: What are the main benefits of using this hand-operated extractor?

A: Key benefits include high extraction accuracy, robust and corrosion-resistant construction, compatibility with standard testing protocols, and flexibility in both sample size and choice of solventsall without the need for an external power supply.
