Hydraulic Compression Testing Machine
Hydraulic Compression Testing Machine
images Send Inquiry
Request To Call Back

Hydraulic Compression Testing Machine

Get a Price/Quote
MOQ : 1 Piece

Hydraulic Compression Testing Machine Specification

  • Capacity
  • 2000 kN (2,000 kgf) (Approx.)
  • Core Components
  • Hydraulic Pump, Load Measuring Unit, Pressure Release Valve
  • Feature
  • Manual Operation, High Accuracy
  • Automation Grade
  • Manual
  • Model No
  • CTM-2000
  • Voltage
  • 230 V
  • Temperature Range
  • Ambient
  • Product Type
  • Hydraulic Compression Testing Machine
  • Application
  • Soil Testing Equipments
  • Power Source
  • Manual / Hydraulic Operation
  • Usage
  • Soil Testing Equipments
  • Accuracy
  • 1% of indicated value
  • Measurement Range
  • 0-2000 kN
  • Frequency
  • 50 Hz
  • Equipment Materials
  • Heavy-Duty Steel Body
  • Type
  • Compression Testing Machine
  • Display Type
  • Analog Dial Gauge
  • Dimension (L*W*H)
  • 920 mm x 620 mm x 1050 mm
  • Weight
  • Approx. 250 kg
  • Pump Type
  • Hand Operated Hydraulic Pump
  • Piston Stroke
  • 50 mm
  • Calibration
  • IS:516/IS:14858 certified
  • Suitable For
  • Concrete cube and cylinder testing
  • Frame Construction
  • High-grade steel, powder coated
  • Oil Tank Capacity
  • 5 Liters
  • Maximum Load Indicated
  • 2000 kN
  • Platen Size
  • 150 mm diameter
  • Pressure Gauge Diameter
  • 160 mm


Hydraulic Compression Testing Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • carton box, export quality also available
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, 14001 ,CE


About Hydraulic Compression Testing Machine

Compression Testing Machine

We are Leading manufacturer and Exporter of Hydraulic Compression Testing Machine for engineering Testing.

Electronic Unconfined Compression Tester:

This is similar with the added advantage of a motorised drive permitting a choice of three constant rates of stain.

SPECIFICATION :
Comprises a screw operated load frame, cap.5000kg with a gear box and motor drive giving 1.25, 1.5, 2.5mm/min. Rates of strain, a pair of cone seating, adaptor for proving ring, and stain dial gauge bracket. Supplied with one pair of male/female coning tools for 38mm dia samples but without ring and dial gauge. Suitable for operation on 230 V, Single Phase A.C. Supply.

ACCESSORIES :Coning tools in pairs (Male & Female) for samples having diameter 38mm, 50mm, 75mm & 100mm







Superior Frame Construction and Durability

Constructed from heavy-duty, powder-coated high-grade steel, the CTM-2000 promises exceptional durability even under intensive laboratory use. The robust design supports long-term reliability and stability during high-pressure compressive strength evaluations.


Precision Measurement and Analog Display

The CTM-2000 features a 160 mm pressure gauge and an analog dial display, offering clear, accurate readings. With an accuracy of 1% and compliance with IS:516/IS:14858 standards, users gain confidence in every measurement and test result.


Manual Hydraulic Operation for Ease and Control

Equipped with a hand-operated hydraulic pump and manual controls, this machine gives operators consistent and direct oversight during testing. The reliable pump mechanism facilitates controlled application of load, ensuring repeatable outcomes.

FAQs of Hydraulic Compression Testing Machine:


Q: How does the CTM-2000 Hydraulic Compression Testing Machine operate?

A: The CTM-2000 functions through a manually operated hydraulic system. Users apply pressure via a hand pump, and results are indicated on an analog dial gauge, making the process straightforward and dependable.

Q: What materials and specimen types can be tested using this machine?

A: The CTM-2000 is suitable for compression tests of concrete cubes, cylinders, and also soil samples, making it versatile for both civil and geotechnical laboratory applications.

Q: When should the machine be calibrated, and what standards does it follow?

A: Calibration should be performed as per laboratory protocols or after intensive usage. The device complies with IS:516 and IS:14858 standards, ensuring reliable calibration and measurement accuracy.

Q: Where is the CTM-2000 commonly used?

A: This compression tester is widely utilized in construction material labs, civil engineering research facilities, and soil testing laboratories across India and globally by distributors, manufacturers, and suppliers.

Q: What is the maximum load capacity of the machine?

A: The CTM-2000 supports a maximum indicated load of 2000 kN (approximately 2,000 kgf), allowing for robust testing of materials under high compressive forces.

Q: What are the main benefits of manual hydraulic operation instead of automatic systems?

A: Manual hydraulic operation offers direct control, easier maintenance, and reliable performance without dependency on electronic automation, making it ideal for laboratories seeking robust and simple equipment.

Q: How is the measurement accuracy assured?

A: The CTM-2000 delivers a measurement accuracy within 1% of the indicated value, supported by regular calibration and adherence to IS standards for consistent, reliable results.
