Bitumen Pentrometer Electronic Automatic

Price 1000.0 INR/ Unit

Get a Price/Quote

MOQ : 10 Units

Bitumen Pentrometer Electronic Automatic Specification

Frequency
50 Hz

Usage
Soil Testing Equipments

Product Type
Bitumen Pentrometer Electronic Automatic

Voltage
220 V AC

Application
Soil Testing Equipments

Automation Grade
Automatic

Temperature Range
5°C to 40°C

Model No
BPEA-01

Accuracy
±0.01 mm

Power Source
Electric

Core Components
Penetration Needle, Electronic Timing Device, Sample Holder

Measurement Range
0-400 Penetration Unit

Feature
Automatic Penetration with Timer, High Accuracy, Digital Display

Equipment Materials
Stainless Steel and High Grade Plastic

Type
Bitumen Penetrometer Electronic Automatic

Display Type
Digital (Electronic)

Dimension (L*W*H)
410 x 280 x 515 mm

Weight
18 kg approx.

Sample Capacity
One test at a time

Ambient Temperature
up to 40C

Operation Mode
Automatic Start/Stop with Inbuilt Stopwatch

Power Consumption
25 W

LCD Display
Yes (Easy Viewing)

Interface
Digital Microprocessor-Based Unit

Penetration Time Selector
0 - 60 seconds digital

Bitumen Pentrometer Electronic Automatic Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Letter of Credit (L/C), Cash Advance (CA), Cash in Advance (CID), Telegraphic Transfer (T/T), Cheque

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Bitumen Pentrometer Electronic Automatic

Bitumen pentrometer electronic automatic

A compact instrument using the latest technologies and programmation tools. The apparatus is supplied complete with outfit for penetration of bituminous materials including needle, holder, 50 g weight and 10 containers.

The test should be performed placing the penetration cup in thermostatically controlled water, using the suitable device as the Digital circulation water bath with conditioning vessel.

Technical Specification

Built-in user friendly software.
Full automatic approach on conductive products and hard bitumen.
Four programmable reference positions for the cone holder assembly.
Stepper motor for penetration depth as low as 0.01 mm.
Programmable penetration time between 0 and 999 min.
Temperature measurement: -10 to 150C.
Range: 0 to 75 mm.
Results: in 1/10 mm on full range.
Displayed resolution: in 1/100 mm.
Position recall for routine tests can be set.
Optoelectronic detection of depth penetration.
Optional automatic level detection for bitumen.
Three last tests displayed with calculated average.
Connection: 2 USB ports 1 for printer or keyboard and 1 for PC.
Adjustable led lamp and magnifying glass.

Standard outfit

Supplied complete with outfit for penetration of bituminous materials (needle, holder, 50 g weight, 10 containers), magnifying lens, low voltage illuminator, centring guide, etc.

Overall dimensions: 720x250x330 mm.
Weight approx: 16 kg.

Automatic Precision in Soil Testing
Ensure high-accuracy bitumen penetration tests with the electronic automatic design. The intuitive digital interface and automatic start/stop operation streamline testing procedures, reducing manual errors and boosting efficiency.

User-Friendly Digital Display
The LCD screen provides clear, legible readouts for each test. With a measurement range of 0400 penetration units, lab technicians can rely on accurate and immediate data retrieval for recordkeeping and analysis.

Robust Build for Reliable Performance
Constructed from stainless steel and high-grade plastic, the Bitumen Penetrometer is engineered for extensive laboratory use. Its precise electronic timing device and core components ensure longevity and reproducible results within soil testing applications.

FAQs of Bitumen Pentrometer Electronic Automatic:

Q: How does the Bitumen Penetrometer Electronic Automatic enhance bitumen penetration testing?

A: The instrument automates the testing process using a digital microprocessor, providing precise results with an accuracy of 0.01 mm. Its built-in timer allows users to select penetration durations from 0 to 60 seconds, optimizing consistency and repeatability in soil and bitumen testing.

Q: What is the recommended ambient temperature for operating this penetrometer?

A: This equipment functions optimally in ambient temperatures ranging from 5C to 40C, making it suitable for varied laboratory environments without compromising performance.

Q: When should the Bitumen Penetrometer be used during soil testing procedures?

A: The penetrometer is employed when evaluating the penetration characteristics of bitumen samples, commonly required in geotechnical analysis and material quality assessment in soil testing laboratories.

Q: Where is the Bitumen Penetrometer typically installed for operation?

A: It is designed for benchtop deployment within laboratories, research facilities, and educational institutions specializing in soil and bitumen analysis.

Q: What is the process of conducting a test with this device?

A: To perform a test, load the sample holder with bitumen, set the desired penetration time on the selector, and initiate the automated start. The device employs its penetration needle and electronic timing system, with results displayed on the digital LCD immediately upon completion.

Q: What benefits does the automatic operation mode offer over manual penetrometers?

A: Automatic mode with inbuilt stopwatch and digital controls eliminates manual timing, enhances accuracy, and reduces user intervention, leading to improved repeatability, efficiency, and reliable data collection.
