Curing Tank .

Get a Price/Quote

MOQ : 1 Set

Curing Tank . Specification

Product Type
Curing Tank

Application
Soil Testing Equipments

Temperature Range
Ambient to 100 C Celsius (oC)

Material
Stainless Steel Inner Chamber, Powder Coated Outer Body

Feature
Automatic Temperature Control, Corrosion Resistant, Digital Display

Accuracy
1 C %

Measurement Range
0 100 C

Voltage
220-240 V Volt (v)

Automation Grade
Semi-Automatic

Usage
Soil Testing Equipments

Model No

Core Components
Heater, Thermostat, Circulation Pump

Power Source
Electric

Capacity
1000 Litres Ltr

Frequency
50 Hz Hertz (HZ)

Equipment Materials
Stainless Steel Inner Chamber, Powder Coated Outer Body

Type
Curing Tank

Display Type
Digital

Dimension (L*W*H)
1000 x 650 x 600 mm Millimeter (mm)

Weight
Approx. 60-80 kg Kilograms (kg)

External Finish
Epoxy Powder Coated

Inner Tank Material
Stainless Steel 304 Grade

Insulation
High grade glass wool for minimum heat loss

Tank Lid
Heavy duty with lifting handle

Cooling Capability
Optional Chiller attachment

Ambient Operating Temperature
5C to 45C

Complies With
IS 9013, ASTM C511 standards

Circulation
Motorized water circulation for uniform temperature

Suitable For
Curing of Concrete Samples, Soil Specimens

Heating Element Power
2000 Watt

Drain System
Provided for easy emptying and cleaning

Heater Type
Immersion Heater

Safety System
Over temperature protection & low water level cutoff

Curing Tank . Trade Information

Minimum Order Quantity
1 Set

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Curing Tank .

CURING Tank (Accelerated) for 15 cm cube moulds 6 nos, fitted with DIGITAL TEMP. Controll;er cum Indicator

As per IS 9013 1978. It is developed to get the compressive strength of 28 days within short period by curing the concrete specimen by any of two methods namely warm-water method and boiling water method.

Double Walled. Outer Made of M.S. Inside made of S.S. With hinged Cover Lid. Long Heaters placed at the bottom. Can accommodate 6 / 12 / 24 / 36 moulds of 15 cm or 12 / 24 / 36 / 72 moulds of 7.06cm with concrete or mortar. Fitted with Microprocessor Based Dual Display Digital Temperature Indicator cum Controller. Temperature Range from 50 C to 100 C. Provided with water circulation arrangement to keep the temperature uniform. Overflow Nozzle is provided. Drain Cock for emptying tank is also fitted at the bottom. Operation on 230 Volts, Single Phase.

Curing Tank Accelerated for 06/12 cube moulds of 150/70.6 mm:

For curing 06 Nos. of 150 mm Cube Moulds or 12 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 230 V, 50 Hz, 32 Amp, Single Phase.

Curing Tank Accelerated for 12/24 cube moulds of 150/70.6 mm:

For curing 12 Nos. of 150 mm Cube Moulds or 24 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 440 V, 50 Hz, Three Phase.

Curing Tank Accelerated for 24/48 cube moulds of 150/70.6 mm:

For curing 24 Nos. of 150 mm Cube Moulds or 48 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 440 V, 50 Hz, Three Phase.

Curing Tank Accelerated for 36/72 cube moulds of 150/70.6 mm:

For curing 36 Nos. of 150 mm Cube Moulds or 72 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 440 V, 50 Hz, Three Phase.

Uniform Temperature and Precision

The Curing Tank utilizes a motorized circulation pump and immersion heater, ensuring even temperature distribution and precise control. Its digital display and automatic controls maintain temperatures between ambient and 100C, offering accuracy within 1C for reliable sample curing.

Robust and Efficient Design

Constructed with a Stainless Steel 304 Grade inner tank and an epoxy powder-coated external finish, this curing tank is built for longevity and corrosion resistance. The heavy-duty insulated design featuring glass wool ensures minimal heat loss, resulting in optimized energy consumption and stable operation.

User-Friendly Operation and Safety

Featuring a heavy-duty lid with a lifting handle, efficient drainage system, and intuitive digital controls, the both easy to use and safe. Integrated safety systems such as over-temperature protection and a low water level cutoff provide peace of mind and secure operation during continuous use.

FAQs of Curing Tank:

Q: How does the Curing Tank maintain uniform temperature throughout the tank?

A: Uniform temperature is achieved using a motorized water circulation system, which ensures even heat distribution by constantly circulating water within the stainless steel chamber. Combined with precise digital temperature control, this feature guarantees reliable specimen curing.

Q: What is the process for draining and cleaning the curing tank after use?

A: The equipped with a dedicated drain system, allowing users to easily empty residual water after testing. Once drained, the inner stainless steel chamber can be rinsed and wiped down for convenient and hygienic cleaning.

Q: When should I use the optional chiller attachment with the curing tank?

A: The optional chiller is recommended when the ambient temperature or required curing conditions need the water to be cooled below room temperature. This is particularly useful in climates or processes where precise, lower temperature curing is critical for soil or concrete samples.

Q: Where is the most effectively utilized?

A: The ideally suited for material testing laboratories, construction quality control labs, and research environments where soil and concrete sample curing is performed in accordance with IS 9013 and ASTM C511 standards.

Q: What are the benefits of having a stainless steel inner tank and epoxy powder coated outer body?

A: Stainless steel ensures corrosion resistance and easy cleaning, while the epoxy powder coated outer body increases durability and protects against environmental wear, ensuring long-lasting performance and easier maintenance.

Q: How does the safety system protect samples and operators during operation?

A: The built-in safety features include over-temperature protection and a low water level cutoff. These automatically prevent overheating and potential equipment damage, safeguarding both the samples under test and users during extended operation.
