Fatigue testing machine

Fatigue testing machine

Send Inquiry

Request To Call Back

Fatigue testing machine

Get a Price/Quote

MOQ : 2 Pieces

Fatigue testing machine Specification

Temperature Range
Ambient to 200C

Capacity
100 kg

Core Components
Motor, Digital Display, Test Fixture

Measurement Range
Up to 10,000 cycles

Power Source
220V AC, Single Phase

Voltage
220 V

Frequency
0.5 to 50 Hz

Accuracy
1% of reading

Automation Grade
Semi-Automatic

Application
Soil Testing Equipments

Usage
Soil Testing Equipments

Product Type
Fatigue testing machine

Feature
Variable speed, precision control

Model No
FTM-100

Equipment Materials
Mild Steel & Stainless Steel

Type
Rotating Bending

Display Type
Digital & Analog

Dimension (L*W*H)
Approx. 900 x 450 x 1000 mm

Weight
Approx. 75 kg

Ambient Humidity
Up to 85% RH

Test Method
Rotating bending fatigue

Safety Features
Overload protection, Emergency stop switch

Operating Environment
Laboratory, Industrial

Noise Level
Less than 70 dB

Motor Power
0.5 HP

Control Mode
Manual and Digital

Sample Material Compatibility
Metal, Alloys, Plastics

Max Sample Diameter
12 mm

Data Output
USB and RS232 port

Finishing
Powder coated & chrome plated

Fatigue testing machine Trade Information

Minimum Order Quantity
2 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Fatigue testing machine

Fatigue testing machine 100kg cm.

Fatigue testing machine 200kg cm.

Fatigue testing machine 300kg cm.

Fatigue Testing Machines is one of the major reasons for failure of the materials used in all engineering designs. It is important to know fatigue properties of most of the materials before using them for actual application. Microteknik make Fatigue Testing Machines of AI-FT series is most suitable for measuring fatigue strength and to draw S-N diagram. These are used by research institute, Auto industries and materials manufacturers. This is a rotating beam type machine where load is applied in reverse bending manner. Standard 8mm diameter specimen is held in special holders at its ends and loaded such that it experiences a uniform bending moment. Specimen is rotated at 4200 RPM by a motor.

Features :

Light weight, compact size, simple design
Table model. No need of foundation
Simple lever systems for changing load
Accurately calibrated as per IS 5075
Machines can be supplied with Nm calibration on request

Technical Specification:

SI No.

Model

AI-FT 200

1

Maximum Bending Moment

Kg

Cm 200

2

Bending Moment Adjustable

Kg

Cm 27-200

3

Ranges

Kg

Cm 25-125, 125-200

4

Gripping dia of Specimen

mm

12

5

Testing dia of Specimen

mm

8

6

Rotating Speed

rpm

42000

7

Accuracy of applied bending moment

1.00%

8

Digital Counter

Digit

8

9

Power required

hp

0.5

10

Main Supply

a.c.

3ph, 415v, 50hz

11

Overall Size (approx) mm

mm

1000 L.X. 500w X 600 h

12

Weight (approx)

Kg

120

Versatile Material Testing

The FTM-100 Fatigue Testing Machine accommodates metals, alloys, and plastics, making it suitable for diverse laboratory and industrial applications. Its compatibility ensures accurate fatigue testing regardless of your material sample, and the robust fixture design supports a maximum sample diameter of 12 mm for comprehensive soil testing equipment assessments.

Advanced Safety and Control

Built with essential safety features like overload protection and an emergency stop switch, this machine offers peace of mind during operation. Choose between manual or digital control modes and utilize variable speed adjustment for precise fatigue testing. The digital and analog displays enhance monitoring and usability.

Precision Data and Flexible Output

Reporting and analysis are streamlined with USB and RS232 data output options. The machine provides measurement ranges up to 10,000 cycles and operates at frequencies from 0.5 to 50 Hz, ensuring reliable, repeatable results for research, manufacturing, or quality control needs.

FAQs of Fatigue testing machine:

Q: How does the FTM-100 Fatigue Testing Machine conduct rotating bending fatigue tests?
A: The machine applies controlled rotating bending stress to the sample, using its motorized drive and adjustable frequency settings. This simulates real-world stress conditions, enabling users to determine the materials fatigue life with high accuracy.

Q: What types of materials are compatible with this fatigue testing machine?
A: The FTM-100 supports sample testing for metals, alloys, and plastics, accommodating a variety of industrial and laboratory requirements. Its robust test fixture is designed for samples up to 12 mm in diameter.

Q: When should I use the emergency stop or overload protection features?
A: Activate the emergency stop switch whenever a hazardous situation arises or in case of unexpected equipment malfunction. The overload protection operates automatically, safeguarding the machine against excessive loads and maintaining safe operation.

Q: Where can the FTM-100 be installed and operated?
A: This testing machine is suitable for laboratory and industrial settings, including locations focused on soil testing. With a compact footprint and low noise output, its easy to integrate within modern workspaces.

Q: What is the process for data collection and output during testing?
A: Data from fatigue tests is displayed on both digital and analog displays and can be saved or exported through the USB and RS232 ports, allowing seamless transfer to computers or external devices for in-depth analysis.

Q: How does variable speed and precision control enhance fatigue testing accuracy?
A: Variable speed and precision control let operators tailor the stress application to specific material behaviors, ensuring that results remain consistent and within an accuracy of 1% of reading.

Q: What benefits do safety and durability features offer for soil testing labs?
A: The powder-coated and chrome-plated finish provides long-term durability and corrosion resistance, while safety mechanisms such as overload protection and emergency stop contribute to secure operation. These features ensure reliable performance in demanding environments.
