Extractor Frame Hydraulic .

Extractor Frame Hydraulic .

Send Inquiry

Request To Call Back

Extractor Frame Hydraulic .

Get a Price/Quote

MOQ : 1 Piece

Extractor Frame Hydraulic . Specification

Power Source
Manual/Hydraulic

Accuracy
High Precision for Laboratory Applications

Automation Grade
Manual

Core Components
Hydraulic Ram, Extraction Frame, Hand Operated Pump

Application
Soil Testing Equipments

Usage
Soil Testing Equipments

Frequency
50 Hz

Feature
Robust Design, High Durability, Corrosion Resistance

Product Type
Extractor Frame Hydraulic

Equipment Materials
Mild Steel Body with Powder Coated Finish

Type
Extractor Frame Hydraulic

Display Type
Analog

Dimension (L*W*H)
540 x 250 x 220 mm (Approx)

Weight
40-50 kg (Approx)

Compatible Moulds
100 mm & 150 mm diameter soil sample moulds

Maximum Extraction Force
50 kN (Approx)

Maintenance
Low Maintenance Required

Color
Blue or As Per Requirement

Operation
Hand Operated Hydraulic System

Extractor Frame Hydraulic . Trade Information

Minimum Order Quantity
1 Piece

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Extractor Frame Hydraulic .

Extractor frame hydraulic:

This extractor Frame is used for taking ut soil samples compacted or undisturbed, from 100 mm dia and 150 mm dia cylinders such as core cutters, Proctor moulds, C.B.R. moulds etc.
Salient Features Specifications : It consists of a 5 Tone capacity hand operated, hydraulic jack mounted on a suitable frame. Two plungers, one for 100 mm dia and the other of 150 mm dia moulds are supplied. One thrust plate for 150 mm dia and one for 100 mm dia specimens are also supplied. Height of thrust plate is adjustable.

Accessories: Set of Plungers adaptors and thrust plates for 38 mm, 50 mm and 75 mm dia specime.

High Precision Extraction for Soil Testing

Engineered for laboratory accuracy, the Extractor Frame Hydraulic provides controlled and reliable extraction of soil specimens for critical analysis. Its analog display and hand-operated hydraulic system ensure consistent results, making it essential for precise soil assessments. The robust frame accommodates standard mould sizes, meeting diverse testing requirements.

Durable Construction and Low Maintenance

Featuring a rugged mild steel body with a protective powder-coated finish, the frame is designed to withstand demanding usage and harsh laboratory conditions. The systems low maintenance requirements reduce downtime, while its corrosion-resistant design ensures longevity and trouble-free operation, optimizing long-term performance.

FAQs of Extractor Frame Hydraulic .:

Q: How is the Extractor Frame Hydraulic used for soil sample extraction?

A: The Extractor Frame Hydraulic is operated manually using its built-in hydraulic hand pump. Place the compatible soil sample mould (100 mm or 150 mm diameter) in position, then use the hand lever to exert hydraulic pressure. The hydraulic ram applies a controlled force, extracting the soil sample efficiently and consistently.

Q: What are the benefits of using this hand-operated hydraulic extractor frame?

A: Key benefits include high extraction precision, robust construction, and corrosion resistance. Its low maintenance needs, manual operation (no power required), and high durability make it ideal for prolonged and frequent use in both laboratory and field applications.

Q: Where can the Extractor Frame Hydraulic be applied?

A: This equipment is primarily used in civil engineering laboratories, research facilities, quality control units, and construction sites for soil testing and sample preparation. It is well-suited for both educational and commercial use.

Q: What makes the Extractor Frame Hydraulic suitable for laboratory use?

A: With its manual hydraulic system, high extraction force (up to 50 kN), and ability to deliver accurate results with high repeatability, the apparatus meets the precise standards needed for laboratory settings. The analog display supports accurate monitoring during operations.

Q: What maintenance is required for the Extractor Frame Hydraulic?

A: Routine cleaning of the powder-coated surfaces and periodic inspection of hydraulic components are recommended. The robust design keeps maintenance minimal, ensuring reliable operation over extended periods.

Q: How does the frame ensure durability and resistance to corrosion?

A: It is constructed from mild steel and powder coated, providing toughness and a protective barrier against corrosion, making it suitable for use in environments where durability is crucial.
