Automatic Compression Testing Machine for Soil Testing

Price 5000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Automatic Compression Testing Machine for Soil Testing Specification

Measurement Range
0 - 2000 kN

Temperature Range
Ambient to 60 C Celsius (oC)

Power Source
Electric

Model No

Application
Soil Testing Equipments

Feature
Automatic Operation, High Precision, Safety Interlocks

Voltage
230 V, Single Phase Volt (v)

Automation Grade
Automatic

Accuracy
1% of indicated load %

Usage
Soil Testing Equipments

Core Components
Load Frame, Hydraulic Pump, Digital Controller

Capacity
2000 kN Kg

Product Type
Automatic Compression Testing Machine

Frequency
50 Hz Hertz (HZ)

Equipment Materials
Mild Steel Body, Powder Coated Finish

Type
Automatic Compression Testing Machine

Display Type
Digital Display

Dimension (L*W*H)
700 mm x 400 mm x 1200 mm Millimeter (mm)

Weight
Approx. 150 kg Kilograms (kg)

Oil Tank Capacity
10 liters

Control Mode
Microprocessor Based Automatic Control

Loading Rate
1.2 kN/sec (adjustable)

Data Output
USB and RS232 ports for PC interface

Platen Size
150 mm diameter

Operating Temperature
10C to 50C

Piston Travel
50 mm

Safety Features
Overload Protection, Emergency Stop

Automatic Compression Testing Machine for Soil Testing Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Automatic Compression Testing Machine for Soil Testing

Automatic Compression Testing Machine

The Automatic Compression Testing Machine has all features of Micro Controller based Compression Testing Machine.

In addition, it has:
1. An automatic load release facility
2. Support for data transmission over distances upto several kilometers. This is useful for testing in the field. (Optional feature)
3. Measurements of Strain with a resolution of upto 0.001 mm (optional feature)
4. Measurement of Flexural Strength (optional feature)
5. Facility to enter the required pace rate, at the beginning of the run

Software: A powerful Analysis and Reporting Software Tools with the following

Features:

An intuitive and easy to use graphical user interface
Facility to list all the runs stored in the digital head/box
Facility to download and plot the data for a selected run
Facility to save test-data along with other information about the sample such as age, sample number and batch name
On -line graph of Load Vs Time
Numerical display of the instantaneous value of the load
Automatic display of a breaking load at the end of the test
Log-in controlled multilevel access
A facility for creating users and enabling /disabling their log-in permissions
A sophisticated reporting tool which can be used to generate-Reports for individual samples with data in graphical of tabular form
Load Vs Time Plot
Stress Vs Time Plot
Calibration report
Batch Summary report
Selective deletion of individual and multiple sample records
Online Help Manual

High Precision Automatic Control
It utilizes a microprocessor-based automatic control system to consistently deliver high-precision soil test results. The digital controller and integrated hydraulic pump ensure that the loading rate can be accurately managed, meeting various soil testing standards. Users benefit from a hands-free testing process that minimizes manual intervention and maximizes reliability.

User-Friendly Interface and Data Connectivity
Equipped with a digital display, USB and RS232 ports, the machine offers seamless data transfer and easy monitoring of testing parameters. Technicians can quickly connect the device to their computers for comprehensive data analysis, enhancing workflow efficiency and record-keeping. The intuitive interface makes operation straightforward, even for new users.

Advanced Safety and Robust Design
Safety is prioritized with overload protection and an emergency stop function, complemented by high-quality construction using powder-coated mild steel. The load frame ensures stability, while safety interlocks protect users during operation. Suitable for a range of operating temperatures, it

is engineered to maintain dependable performance in busy laboratory environments.

FAQs of Automatic Compression Testing Machine for Soil Testing:

Q: How does it ensure high accuracy during soil compression testing?

A: It employs a microprocessor-based automatic control system with advanced sensors and digital feedback, ensuring loading rates and force measurements are maintained within 1% of the indicated load. This guarantees reliable, reproducible soil test results across its full measurement range.

Q: What safety features are integrated into the machine for operator protection?

A: The machine includes overload protection and an emergency stop button. Safety interlocks are also built-in, which automatically halt operation under unsafe conditions, ensuring operator safety and protecting the equipment during testing.

Q: When should I use the machine in my soil testing workflow?

A: It is ideal for laboratory soil compression testing when accurate, automatic measurements are required. Use it during geotechnical investigations, construction quality control, or any process that demands high-precision soil strength evaluation.

Q: Where can the machine be installed in a laboratory setting?

A: Due to its compact dimensions (700 mm x 400 mm x 1200 mm) and sturdy design, the machine can be installed on laboratory floors or dedicated testing workstations. Its weight and stable load frame help minimize vibrations and ensure consistent results.

Q: What is the process for exporting data from the machine to a PC?

A: Data export is straightforward using the built-in USB and RS232 interfaces. Connect the machine to a computer, and the digital controller enables seamless transfer of test results for analysis and record-keeping via compatible software.

Q: How does automatic operation benefit my testing routine?

A: Automatic operation reduces manual input during the testing process, thereby minimizing human error and enhancing repeatability. It streamlines workflow, saves time, and ensures consistent soil test measurements, all while providing detailed digital feedback and data management.

Q: What materials and construction features make the machine durable for long-term use?

A: The machine features a robust mild steel body with a powder-coated finish, ensuring resistance to wear, corrosion, and laboratory environments. Core components such as the load frame, hydraulic pump, and digital controller are engineered for sustained, accurate performances over years of heavy usage.
