Jaw crusher .

Price 415000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Jaw crusher . Specification

Model No

Usage
Soil Testing Equipments

Frequency
50 Hz Hertz (HZ)

Power Source
Electric

Material
Mild Steel (MS)

Automation Grade
Semi-Automatic

Application
Soil Testing Equipments

Accuracy
High precision for size reduction %

Feature
Corrosion Resistant, High Crushing Ratio, Easy Operation

Voltage
220-240 V Volt (v)

Core Components
Jaw Plates, Shaft, Flywheel

Capacity
250 kg/hr to 5000 kg/hr Pcs/hr

Product Type
Jaw crusher

Measurement Range
Up to 100 mm feed size

Equipment Materials
Mild Steel (MS)

Type
Jaw crusher

Dimension (L*W*H)
1100 x 400 x 900 mm Millimeter (mm)

Weight
Approx. 150 - 300 kg Kilograms (kg)

Crushing Capacity
250 - 5000 Kg per hour

Drive
Belt Pulley Drive

Motor Power
3 HP to 7.5 HP

Discharge Size
Up to 6 mm

Jaw Material
Manganese Steel

Feed Size
Up to 100 mm

Jaw crusher . Trade Information

Minimum Order Quantity
1 Piece

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

Jaw crusher . About

Jaw crusher:

1. Designed to speed up crushing of Aggregates, Ores, Mineral, Coal and Similar Materials
2. Compact and rugged for laboratory and small production units
3. Manganese steel jaws adjustable up to 6mm opening
4. 250kg materials can be crushed in approx eight hours
5. Supported with strong steel frame
6. Suitable for operation with 440 V, Three Phase A.C. Supply

Jaw crusher 4x6 with motor & switch
Jaw crusher 5x6 with motor & switch
Jaw crusher 6x8 with motor & switch
Jaw crusher 8x12 with motor & switch

Efficient Size Reduction for Soil Testing

Engineered specifically for soil sample preparation, the Jaw Crusher offers high precision size reduction, handling feed sizes up to 100 mm and crushing them down to as small as 6 mm. Its robust construction and manganese steel jaw plates ensure consistent performance, making it ideal for geotechnical laboratories and material research facilities.

Durable and User-Friendly Design

This jaw crusher is constructed using high-grade materials like manganese steel for the jaw plates and mild steel for the main body, ensuring longevity and corrosion resistance. The semi-automatic operation, convenient belt-pulley drive, and easy-to-use interface make it suitable for both experienced and novice users in soil testing applications.

Versatile Application and High Throughput

With a crushing capacity ranging from 250 to 5000 kg per hour, the meets the demands of various soil testing and sample preparation projects. Its compact size allows for convenient installation in laboratories, while its high throughput supports quick processing of multiple samples for reliable analytical results.

FAQs of Jaw crusher:

Q: How does the Jaw Crusher operate and what are its core components?

A: The Jaw Crusher operates via a belt pulley drive powered by a 3 HP to 7.5 HP electric motor. Its primary components include manganese steel jaw plates, a durable shaft, and a flywheel, all contributing to efficient and consistent size reduction for soil testing samples.

Q: What types of materials can be processed with this jaw crusher, and what is its crushing capacity?

A: This crusher is specifically designed for soil testing and can process a variety of soil and similar laboratory samples. It offers a crushing capacity ranging from 250 to 5000 kg per hour, making it suitable for both small and large-volume testing requirements.

Q: Where is this jaw crusher typically used, and who are the ideal users?

A: The Jaw Crusher is primarily used in geotechnical laboratories, research institutes, and soil testing centers. It is well-suited for soil engineers, laboratory technicians, researchers, and educational institutions involved in material analysis.

Q: What is the process for size reduction using this jaw crusher?

A: Sample material, with a feed size up to 100 mm, is fed into the crushers chamber. The manganese steel jaw plates move to crush the material down to the desired discharge size, as small as 6 mm, ensuring particle uniformity for accurate soil analysis.

Q: What are the main benefits of using the Jaw Crusher for soil testing?

A: Key benefits include high crushing precision, corrosion resistance, easy operation, high throughput capacity, and reliable performance. These features ensure accurate preparation of soil samples for further testing and analysis.

Q: How easy is it to operate and maintain this jaw crusher?

A: The designed for user-friendly operation with semi-automatic functions and simple controls. Its construction allows for straightforward maintenance, as the jaw plates and other critical components are easily accessible for inspection and replacement.
