Devil Abbrasion Testing Machine

Devil Abbrasion Testing Machine

Send Inquiry

Request To Call Back

Devil Abbrasion Testing Machine

Get a Price/Quote

MOQ : 1 Piece

Devil Abbrasion Testing Machine Specification

Measurement Range
Up to 20 kg

Voltage
220 V

Application
Soil Testing Equipments

Feature
Heavy Duty Construction, Accurate Results

Usage
Soil Testing Equipments

Product Type
Devil Abbrasion Testing Machine

Frequency
50 Hz

Temperature Range
Ambient

Core Components
Abrasion Drum, Motor

Automation Grade
Semi-Automatic

Power Source
Electric

Model No
DEVIL-ABR-001

Accuracy
±1%

Capacity
20 kg

Equipment Materials
Mild Steel

Type
Abrasion Testing Machine

Display Type
Analog

Dimension (L*W*H)
640 mm x 440 mm x 510 mm

Weight
Approx. 60 kg

Operating Principle
Rotational Drum Abrasion

Finish
Powder Coated

Rotation Speed
30-33 rpm

Sample Size
50 mm to 70 mm

Number of Abrasion Wheels
1

Devil Abbrasion Testing Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Devil Abbrasion Testing Machine

Devil abbrasion testing machine

For the determination of resistance of aggregate to wear by abrasion. Two hollow cylinders, closed at one end and provided with tightly fitting covers at the other end. The inside diameter of the cylinder 20 cms and 34 cms depth. The cylinders are mounted on a shaft at an angle of 30 with the axis of rotation. The shaft rotates at 30-33 rpm through a reduction gear, coupled to a motor. Suitable for operation on 440 volts, three phase, 50 cycles, AC supply. Supplied complete with a counter and push button starter. With 12 nos cast iron spheres or steel spheres (steel balls) hardened, approx. 48 mm in diameter, each weighing 380-445.

Rugged Construction for Reliable Performance

Crafted from premium mild steel and finished with a protective powder coating, the Devil Abrasion Testing Machine is built to last. Its robust construction withstands daily wear and tear, making it suitable for intense usage in soil testing laboratories. The heavy-duty components, including the abrasion drum and motor, contribute to consistent and accurate results for every test.

Precise Soil Abrasion Analysis

Utilizing a rotational drum abrasion method, this machine simulates real-world abrasion on samples ranging from 50 mm to 70 mm. Its analog display and semi-automatic operation allow seamless control and monitoring. With an accuracy of 1% and a measurement capacity up to 20 kg, it provides dependable soil abrasion data to support engineering studies and material assessments.

FAQs of Devil Abbrasion Testing Machine:

Q: How does the Devil Abrasion Testing Machine operate?

A: The machine employs the rotational drum abrasion technique, where a single abrasion wheel cycles samples between 30-33 rpm. The soil sample is placed in the abrasion drum, and the machine, powered by a reliable motor, subjects it to controlled wear analysis, delivering accurate data via an analog display.

Q: What types of samples can be tested with this machine?

A: You can test soil specimens with diameters ranging from 50 mm to 70 mm and weight up to 20 kg. This versatility makes the device suitable for various soil testing scenarios in geotechnical and construction labs.

Q: When should I use the Devil Abrasion Testing Machine in my testing process?

A: Use this device during the abrasion assessment phase of soil testing, typically after sampling preparation and before conducting compressive or other strength-related tests. It accurately simulates real-world abrasion, helping determine material durability.

Q: Where is the Devil Abrasion Testing Machine commonly used?

A: This equipment is primarily used in geotechnical labs, research institutions, civil engineering departments, and soil testing facilities throughout India and abroad, wherever robust soil analysis is required.

Q: What is the procedure for conducting a test using this machine?

A: Place your prepared sample inside the abrasion drum, set the desired operating parameters, and start the motor. The sample undergoes abrasion at a controlled speed (30-33 rpm) until the process concludes. The analog display provides real-time progress and results.

Q: What are the main benefits of using the Devil Abrasion Testing Machine?

A: Key benefits include its heavy-duty construction for long-term reliability, high measurement accuracy (1%), simple operation, and the ability to handle a range of sample sizes and weights for versatile soil testing needs.
