Compact Plc With Programmer

Get a Price/Quote
MOQ : 1 Piece

Compact Plc With Programmer Specification

  • Application
  • Electrical Teaching Equipment
  • Accuracy
  • ±1% digital signal
  • Humidity
  • Operating: 10%~90% RH (non-condensing)
  • Frequency
  • 50/60 Hz
  • Display Type
  • Built-in LED and Segment Display
  • Max Height
  • 135 mm
  • Measuring Range
  • Digital 0~24V DC I/O
  • Power Supply
  • 220V AC ±10%, 50/60Hz
  • Test Range
  • Digital signal control, input/output range up to 24V DC
  • Specimen Size
  • Standard PLC module size
  • Resolution
  • 1 bit
  • Operating Voltage
  • 24V DC internal; 220V AC external supply
  • Equipment Type
  • Compact PLC With Programmer
  • Port Size
  • RS232 / USB
  • Mounting Type
  • DIN Rail
  • Features
  • Integrated Programming Unit, DIN Rail Mounting, Modbus Support
  • Number of Specimens
  • Configurable I/O channels
  • Interface Type
  • RS232 / USB
  • Response Time
  • <10 ms
  • Usage
  • Electrical Teaching Equipment
  • Temperature
  • components for thermostatic temperature control
  • Automation Grade
  • Automatic and Manual
  • Capacity
  • Supports up to 16 digital inputs and outputs
  • Machine Weight
  • 2.5 kg
  • Test Speed
  • Programmable, 0.1~50 cycles/sec
  • Test Width
  • Standard modules, 35mm DIN rail mount
  • Control Mode
  • Microcontroller-based automatic and manual
  • Firmware Upgrade
  • Via USB
  • Safety Standard Compliance
  • CE, RoHS
  • CPU Type
  • Embedded ARM Cortex-M
  • Cooling
  • Convection passive
  • Expansion Capability
  • Supports up to 2 expansion modules
  • Digital Input Channels
  • 8
  • Digital Output Channels
  • 8
  • Working Environment
  • Industrial Lab/Test Bench
  • Protection Class
  • IP20
  • Status Indicators
  • LEDs for Power, Input, Output, Error
  • Reset Function
  • Manual and Programmable
  • Input Isolation
  • Opto-isolator
  • Data Retention
  • EEPROM backup for programs
  • Analog Input Channels
  • 2
  • Programming Method
  • Ladder Logic, Function Block, Instruction List
  • Memory Capacity
  • 32K Steps


Compact Plc With Programmer Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Supply Ability
  • 100 Pieces Per Week
  • Delivery Time
  • 1 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • carton box, export quality also available
  • Main Export Market(s)
  • Middle East, Asia, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, 14001 ,CE


Compact Plc With Programmer About

Compact Plc With Programmer

  • Programmable logic controller used to operate different Pneumatic control system with all accessories soft ware.
  • Portable training system integrates an panel, networking, and a variety of programming commands in order to simulate processes.
  • In addition to a discrete I/O simulator with discrete switches and indicators, the system includes application circuits and components for thermostatic temperature control, and variable speed motor control.



Advanced Programming Flexibility

This PLC supports multiple programming languages, including Ladder Logic, Function Block, and Instruction List, making it suitable for varied training and industrial requirements. The integrated programming unit and USB firmware upgrade capability streamline development and maintenance, facilitating both instructional and real-world automation scenarios.


Optimized for Safety and Durability

Engineered with industrial-grade components, the PLC boasts IP20 protection, opto-isolated digital inputs, and convection cooling. Its compliance with CE and RoHS standards assures safety and environmental responsibility, while EEPROM backup safeguards programs during power loss.


Comprehensive Connectivity and Control

Offering RS232 and USB ports along with Modbus support, this PLC provides seamless integration into modern and legacy systems. DIN rail mounting and support for up to 2 expansion modules enhance adaptability for electrical teaching or industrial automation, supporting flexible I/O configurations up to 16 digital channels.

FAQs of Compact Plc With Programmer:


Q: How can I program the Compact PLC and what methods are supported?

A: Programming can be performed using the integrated programming unit, supporting Ladder Logic, Function Block, and Instruction List methods. Firmware upgrades and program management are conducted via the USB port for efficient setup and updates.

Q: What are the main benefits of using this PLC in an electrical teaching environment?

A: Its compact size, versatile programming languages, built-in status indicators, and expansion capability make it ideal for illustrating real-world automation scenarios. The platforms flexibility helps students gain practical skills relevant to modern industry.

Q: When is it appropriate to expand the I/O capacity, and how is it done?

A: Expansion is recommended when your application requires more than 8 digital inputs or outputs. You can connect up to two additional expansion modules, supporting a total of 16 digital I/Os, by mounting them on a standard 35mm DIN rail.

Q: Where can this PLC be installed, and what mounting options are available?

A: Designed mainly for industrial labs and test benches, this PLC mounts easily on a 35mm DIN rail. Its compact design and passive cooling make it suitable for standard electrical enclosures.

Q: What safety and data retention features are included?

A: The PLC features IP20-rated protection, opto-isolated inputs for signal integrity, CE and RoHS compliance, and EEPROM backup to maintain program integrity during power interruptions.

Q: How does the PLC ensure quick response and accurate control?

A: With a response time of less than 10 ms, programmable test speeds (0.150 cycles/sec), and 1% digital signal accuracy, the PLC delivers reliable digital signal control within the 024V DC range.
