Multi Pump Test Rig

Multi Pump Test Rig

Send Inquiry

Request To Call Back

Multi Pump Test Rig

Get a Price/Quote

MOQ : 1 Unit

Multi Pump Test Rig Specification

Hardness
Mild Steel Structure (Powder Coated)

Port Size
1/2 inch BSP

Equipment Type
Multi Pump Test Rig

Display Type
Digital LCD Display

Accuracy
1% of full scale

Usage
Fluid Machines Equipments

Humidity
Up to 90% RH (Non-condensing)

Mounting Type
Floor Mounted

Operating Voltage
230 V AC

Gas Pressure
N/A (Water Test Rig)

Features
Three pumps (Centrifugal, Gear, Reciprocating), high-accuracy measurement, sturdy frame, rust-proof tank, energy efficient motors, easy maintenance, mobile structure with locking wheels

Measuring Range
Flow: 0-25 LPM, Pressure: 0-2.5 kg/cm

Response Time
<2 seconds

Max Height
1100 mm

Product Type
Multi Pump Test Rig

Resolution
0.1 LPM/0.01 kg/cm2

Power Supply
230 V AC, 50 Hz, Single Phase

Test Range
0-25 LPM (flow), 0-2.5 kg/cm2 (pressure)

Temperature
Ambient to 45C

Specimen Size
Standard pump mounting base provided

Application
Fluid Machines Equipments

Automation Grade
Semi-Automatic/Automatic (as per model)

Interface Type
Standard panel, RS232/USB optional

Frequency
50 Hz

Number of Specimens
1 at a time

Capacity
0.5 HP to 1 HP per pump

Machine Weight
Approximately 70-85 kg

Test Speed
Variable (Programmable as per requirement)

Test Width
250 mm

Test Stroke
Up to 200 mm

Control Mode
Manual/Automatic (PLC based optional)

Test Medium
Water

Finish
Epoxy powder coated for corrosion resistance

Accessories
Flexible hoses, quick-coupling joints, calibration certificates

Instrumentation
Digital Flow Meter, Digital Pressure Gauge, Digital Voltmeter & Ammeter

Tank Capacity
30 Litres minimum

Dimensions (approx.)
1200 mm (L) x 650 mm (W) x 1100 mm (H)

Safety Features
Overload protection, anti-leakage mechanical seal, emergency stop

Material of Construction
Powder Coated Mild Steel/Fitted with Stainless Steel hardware

Priming System
Built-in for centrifugal pump

Motor Make
ISI marked, copper winding motors

Pump Types Included
Centrifugal Pump, Gear Pump, Reciprocating Pump

Mobility
Heavy-duty lockable castor wheels

Multi Pump Test Rig Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Multi Pump Test Rig

Multi-Pump Test Rig: MTFM-11

The equipment comprises a water reservoir and five pump positions (four active). Each pump position uses pipe work and sensors optimized to the type of pumps it is intended for. Positions 1, 2a and 2b are optimized for high flows at low heads, such as the rot dynamic pumps, whereas positions 3 and 4 are suitable for lower flows but higher pressures as obtained from the positive displacement pumps. Positions 2a and 2b are mutually exclusive as they share the same motor drive. Switching between any of the four installed active pumps is simple requiring only isolating valve changes and control panel selection.

DEMONSTRATION CAPABILITIES

Determining the effect of speed on the performance of pumps.
Understanding the difference between rot dynamic pumps and positive displacement pumps.
Understanding the effect of system resistance.
Investigating the effect of suction losses on a centrifugal pump.

TECHNICAL SPECIFICATIONS

For rot dynamic pumps:

Pressure head vs. flow
Power absorbed vs. flow
Pump efficiency vs. flow

For positive displacement pumps:

Flow vs. pressure head
Power absorbed vs. pressure head
Volumetric efficiency vs. pressure head

Contains five different pump positions (four active at the same time). Digital readout enables mounting of selected pump
Centrifugal pump and gear pump supplied as standard
Axial pump, flexible impeller pump, turbine pump, diaphragm pump, plunger pump and a second centrifugal pump are all available as accessories
Series/parallel pump demonstrations can be performed with the second centrifugal pump option
Control valve incorporated upstream of each pump to demonstrate the effect of suction loss on performance
A PC is used to set the required speed of the pump(s) on test. A separate mimic diagram for the selected pump(s) on test displays the important measured and calculated variables
Electronic measurement of flow, pressure head, suction head and motor torque
Optional volumetric flow measurement system for reciprocating pumps
Data logging and educational software included

Note: The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. MICROTEKNIK keeps the right to modify the content in the product without prior notice.

Comprehensive Pump Compatibility

This test rig supports three core pump types: centrifugal, gear, and reciprocating. By integrating these commonly used pumps on a single platform, users can easily compare performance, understand operational differences, and run a wide array of experiments suitable for fluid machinery studies or industrial assessment.

Precision Digital Instrumentation

Equipped with digital flow meters, pressure gauges, voltmeters, and ammeters, the test rig delivers precise measurements with 1% accuracy and swift response time. The LCD digital display ensures results are clear and easy to interpret, while calibration certificates add credibility to the data generated.

Robust & Safe Design

Constructed from powder-coated mild steel with stainless steel components, the rig resists corrosion and ensures durability. Safety is prioritized through features like overload protection, anti-leakage mechanical seals, and an emergency stop, creating a secure testing environment for users.

Versatile Control & Mobility

Users can manage the rig either manually or via optional PLC-based automation. Heavy-duty lockable castor wheels provide convenient movement and secure positioning, making it suitable for various laboratory and industrial spaces. These features together ensure operational flexibility and ease of use.

FAQs of Multi Pump Test Rig:

Q: How does the Multi Pump Test Rig facilitate the testing of different pump types?

A: The rig includes centrifugal, gear, and reciprocating pumps as part of its design. Each can be mounted and operated using the provided standard base, allowing users to switch between pumps easily and observe their performance under different test conditions.

Q: What is the process for conducting a test using this test rig?

A: Begin by mounting the chosen pump on the supplied base, connect the water lines with flexible hoses and quick-coupling joints, and set initial parameters on the control panel. Power on the rig, monitor measurements via digital displays, and adjust speed or control modes as needed. All instrumentation provides real-time feedback, and built-in safety features protect against overload or leakage.

Q: When is this test rig most beneficial in a laboratory or industrial setting?

A: This equipment is ideal whenever precise analysis of pump performance or comparison of different pump mechanisms is required. Its particularly useful for educational labs, R&D departments, and manufacturing quality checks where repeatable, reliable pump testing is essential.

Q: Where can the Multi Pump Test Rig be effectively deployed?

A: With its sturdy, floor-mounted design and mobile locking castor wheels, this unit fits seamlessly into university laboratories, training centers, research facilities, and industrial workshops throughout India and abroad.

Q: What makes the rig easy and safe to use for repeated experiments?

A: Features such as programmable speed, manual or automatic control options, user-friendly interface, emergency stop, overload protection, and anti-leakage seals ensure safe, efficient, and consistent testing while allowing quick setup for repeated trials.

Q: How does the digital instrumentation enhance measurement accuracy and usability?

A: The inclusion of digital LCD flow and pressure gauges, along with voltmeter and ammeter, provide precise, instantaneous results with a resolution of 0.1 LPM and 0.01 kg/cm. This minimizes manual reading errors and streamlines data collection for accurate analysis.

Q: What are the primary benefits of using this Multi Pump Test Rig in fluid machines equipment applications?

A: Users experience reliable measurement, quick specimen setup, enhanced safety, and adaptability for variable testing needs. The mobile, corrosion-resistant structure supports both long-term laboratory and industrial use, maximizing educational value and operational efficiency.
