Laser Information Transmission Assembly

Price 10 INR/ Piece

Get a Price/Quote
MOQ : 1 Piece

Laser Information Transmission Assembly Specification

  • Frequency
  • 850 nm - 1550 nm (Optical band)
  • Automation Grade
  • Semi-automatic
  • Temperature Range
  • -20C to 60C
  • Product Type
  • Laser Information Transmission Assembly
  • Power Source
  • DC (12V/24V)
  • Feature
  • High Precision Alignment, Low Signal Loss, EMI Shielding
  • Capacity
  • High bandwidth (multi-channel transmission up to 10 Gbps)
  • Core Components
  • Laser Diode, Photodiode Receiver, PCB Control Board
  • Application
  • General Lab Equipments
  • Model No
  • LITA-5466335
  • Accuracy
  • 0.02% Signal Error Rate
  • Voltage
  • 12V/24V DC
  • Usage
  • General Lab Equipments
  • Measurement Range
  • Up to 50 meters (Line-of-Sight Optical Transmission)
  • Equipment Materials
  • Aluminum Alloy, Optical Glass, Electronic Components
  • Type
  • Assembly (for Laser Information Transmission)
  • Display Type
  • Digital signal monitoring
  • Dimension (L*W*H)
  • 350 mm x 180 mm x 120 mm
  • Weight
  • Approx. 2.5 kg


Laser Information Transmission Assembly Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • carton box, export quality also available
  • Main Export Market(s)
  • Asia, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, 14001 ,CE


About Laser Information Transmission Assembly

Laser Information Transmission Assembly

  • Complete package for performing laser signal transmission experiments.
  • The signal transmitted directly from the laser to the photodiode by putting the opening of the photodiode box in the path of the beam.
  • It transmitted via an optical fiber.
  • Composition of the assembly- 1 multifunction laser box - 1 photodiode box, - 2 amplification boxes,1 filtering capacitor box, - 1 1 m optical fiber- 1 jack-female cord, - Banana plugs.





Advanced Optical Wireless Transmission

Utilizing a laser-based optical transmission method, this assembly offers high-speed, reliable communication for lab environments. Its advanced alignment technology and low signal loss ensure data integrity over distances up to 50 meters. The use of secure SC/APC optical connectors further enhances signal quality and performance.


Versatile and Durable Design

Built with robust materials such as aluminum alloy and optical glass, the assembly is dust and moisture resistant, suitable for various laboratory settings. Its electrical isolation between input and output, along with EMI shielding, guarantees safe and interference-free data transmission.


Flexible Operation and Monitoring

With support for both digital and analog signals and a semi-automatic operation mode, this assembly adapts easily to different lab setups. The integrated digital signal monitoring display and passive heatsink cooling enable continuous, reliable operation within a broad temperature and humidity range.

FAQs of Laser Information Transmission Assembly:


Q: How does the LITA-5466335 Laser Information Transmission Assembly transmit data?

A: The assembly uses a laser-based optical wireless transmission method, leveraging high-precision alignment lasers to send data through an optical band of 850 nm to 1550 nm. This enables high-bandwidth, multi-channel transmission up to 10 Gbps across distances up to 50 meters under line-of-sight conditions.

Q: What types of signals are supported by this device?

A: The LITA-5466335 supports both digital (such as Ethernet and Serial) and analog signal types, offering flexibility for a range of laboratory equipment and communication requirements.

Q: When should I use this assembly in my laboratory setup?

A: This assembly is ideal for situations requiring high-speed, reliable, and secure data transmission between lab instruments. Its high bandwidth and electrical isolation make it suitable for environments where data accuracy and signal quality are critical.

Q: Where can the assembly be mounted or installed?

A: The device is designed for desktop tabletop mounting or rack mounting, providing easy integration into most standard laboratory setups or equipment racks.

Q: What process is involved in connecting devices to this assembly?

A: Devices connect to the assembly using SC/APC optical connectors for input and output. The process involves aligning the optical cables to the connectors, ensuring stable line-of-sight conditions, and monitoring signal status via the built-in digital display.

Q: How does the product ensure operational safety and durability?

A: The assembly conforms to IEC 60825-1 Class 1 laser safety standards, operates within a protected aluminum alloy and optical glass housing, and is resistant to dust and moisture. It also offers electrical isolation, EMI shielding, and passive heatsink cooling for reliability.

Q: What are the primary benefits of using the LITA-5466335 in a lab environment?

A: The main advantages include high-precision, low-loss signal transmission, support for various signal types, real-time digital monitoring, and a robust, semi-automatic design that withstands harsh laboratory conditions while maintaining data accuracy with a 0.02% signal error rate.
