Function Generators 2 Mhz

Product Description

Function Generators 2 Mhz

• 6 digits display
• Frequency meter up to 2 MHz

Features

• Signal shape: Sine, triangle, square, TTL, ramp
• Frequency: 0.2 Hz
• 2 MHz in 6 calibres
• Display: 6 digits Red LED
• Frequency meter: 0.5 Hz to 30 MHz
• Unamplified output: BNC socket, impedance 50©
• Voltage: 20 VDC at 1 M - 10 VDC at 50©
• Attenuation: 0 dB / 20 dB / 40 dB / 60 Db
• Continuous offset: 0 to ± 10 V on 1 M - to ± 5 V on 50©
• Cyclic ratio: 10 to 90%
• Distortion: <1% from 20 Hz to 20 kHz- Input vcf: External sweep: Voltage: -5 at 0 V - Input
• impedance: 10 k©  10%
• Power supply: 110-127 VAC ± 10% - 220-240 VAC ± 10% 50-60 Hz ± 2 Hz
• Dimensions (W x D x H): 250 x 280 x 105 mm
• Mass: 2.5 kg
