Domestic Home Wiring Demonstration Panel

Price 1000.0 INR/ Piece

Get a Price/Quote
MOQ : 1 Piece

Domestic Home Wiring Demonstration Panel Specification

  • Mounting Type
  • Bench Top/Table Mount
  • Response Time
  • Immediate (via switches)
  • Product Type
  • DOMESTIC HOME WIRING DEMONSTRATION PANEL
  • Interface Type
  • Push button, switches and indicator panel
  • Power Supply
  • 230 V AC, 50 Hz, Single Phase
  • Temperature
  • 10C to 40C
  • Features
  • Demonstrates domestic wiring schemes, safety fuses, power points, fluorescent and incandescent lamp holders, and earth connections
  • Equipment Type
  • DOMESTIC HOME WIRING DEMONSTRATION PANEL
  • Humidity
  • Up to 95% RH (non-condensing)
  • Display Type
  • Pilot lamps and analog meters
  • Frequency
  • 50 Hz
  • Application
  • DOMESTIC HOME WIRING DEMONSTRATION PANEL
  • Automation Grade
  • Manual
  • Max Height
  • 450 mm
  • Operating Voltage
  • 230 V AC
  • Usage
  • Educational Demonstration of Domestic Wiring
  • Capacity
  • Multiple loads (up to 800W total)
  • Machine Weight
  • 12 kg
  • Control Mode
  • Manual and Demo Switch operated
  • Wiring Type
  • PVC insulated copper wires
  • Color
  • White and Blue finish
  • Load Indicators
  • Neon indicator lamps
  • Protection
  • 2 A/5 A Fuse protection provided
  • Panel Material
  • MS Powder Coated Sheet
  • Included Accessories
  • Instruction manual, spare fuses, test probes
  • Dimensions
  • 600 mm x 500 mm x 200 mm
  • Demonstration Circuits
  • One-way, two-way, staircase, Godown wiring, etc.
  • Connections
  • Front panel terminals and plugs
  • Sockets Provided
  • 2-pin and 3-pin universal sockets


Domestic Home Wiring Demonstration Panel Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • Packaging Details
  • Carton Box, Export Quality also Available
  • Main Export Market(s)
  • Asia, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, 14001, CE


About Domestic Home Wiring Demonstration Panel

Domestic Home Wiring Demonstration Panel

Suppliedwith 3 Phase Synchronous Motor 1HP, DC source with

ControlPanel fitted with Necessary Meters & 2 Nos of Variable Voltage DC Source



Versatile Wiring Demonstrations

Gain hands-on experience with a wide array of domestic wiring circuits, including one-way, two-way, staircase, and godown configurations. This demonstration panel allows students and trainees to explore real-life electrical setups while ensuring safety through integrated fuse protection and indicator lamps.


Durable, Safe, and User-Friendly Design

Constructed with a powder-coated MS sheet, this unit boasts resilience and high electrical safety standards. Its intuitive controlsmanual switches, push buttons, indicator lamps, and universal socketsmake it ideal for repeated educational use in classrooms or laboratories.


Comprehensive Kit and Easy Operation

The panel comes with clearly marked terminals, instruction manual, spare fuses, test probes, and user-friendly control features. This kit empowers instructors and trainees to operate, monitor, and troubleshoot various domestic circuits safely and efficiently.

FAQs of DOMESTIC HOME WIRING DEMONSTRATION PANEL:


Q: What types of wiring circuits can be demonstrated using this panel?

A: This panel supports demonstrations of several domestic wiring schemes, such as one-way, two-way, staircase, and godown wiring, providing comprehensive hands-on learning for students and trainees.

Q: How is safety ensured during operation of the demonstration panel?

A: Safety is ensured through integrated 2A/5A fuse protection, clearly labeled front panel terminals, and pilot lamps/analog meters for real-time monitoring. Only PVC insulated copper wires are used, and all components meet high safety standards.

Q: What accessories are included with the panel for classroom setup?

A: Each unit is supplied with an instruction manual, spare fuses, test probes, and all the necessary hardware for immediate use. The panel is also bench-top/table mountable for easy placement in educational settings.

Q: How does the panel help in practical learning of domestic wiring?

A: The panel allows users to set up, operate, and observe multiple domestic wiring configurations in real time. Load indicators and pilot lamps provide visual feedback, while manual controls make the learning process interactive and engaging.

Q: When and where is this panel best utilized?

A: This demonstration panel is best utilized in educational institutions, technical training centers, and laboratory environments for live demonstrations of home wiring concepts and safety practices.

Q: What are the benefits of using a manual demo switch operated panel?

A: Manual and demo switch operations foster direct interaction, encouraging deeper understanding and troubleshooting abilities among learners. Immediate response times and clear indications enhance the practical learning experience.
