Digital Universal Testing Machine.

Digital Universal Testing Machine.

Send Inquiry

Request To Call Back

Digital Universal Testing Machine.

Get a Price/Quote

MOQ : 1 Piece

Digital Universal Testing Machine. Specification

Max Height
2000 mm

Equipment Type
Digital Universal Testing Machine

Product Type
Digital Universal Testing Machine

Gas Pressure
Ambient

Accuracy
1%

Operating Voltage
220V AC

Application
Strength of Material Testing Equipments

Features
Programmable Test Cycles, Emergency Stop, Live Data Display

Test Range
0 - 100 kN

Power Supply
220V AC, 50 Hz

Port Size
Standard Universal Jaws

Specimen Size
Round: up to 40 mm, Flat: up to 30 mm

Resolution
0.01 kN

Frequency
50 Hz

Response Time
Instantaneous

Number of Specimens
1

Display Type
Digital LCD

Usage
Strength of Material Testing Equipments

Humidity
80%

Automation Grade
Automatic

Temperature
10C to 35C

Mounting Type
Floor Mounted

Interface Type
USB, RS232

Measuring Range
1% to 100% of machine capacity

Capacity
10 to 100 kN

Machine Weight
850 kg

Test Speed
0.1 to 500 mm/min adjustable

Test Width
400 mm

Test Stroke
900 mm

Control Mode
Digital / PLC Control

Data Storage
Built-in Memory and PC Connectivity

Sample Positioning
Auto Centering

Crosshead Travel
900 mm

Testing Standards
ASTM, IS, ISO

Color
Blue & White

Load Cell Type
High Precision

Motor Type
Servo Drive Motor

Safety
Interlocked Guards

Frame Type
Rigid 4-column

Protection
Overload & Overtravel

Calibration
Digital, Certified

Software
Analysis & Reporting Included

Grip Type
Adjustable, Self-aligning

Digital Universal Testing Machine. Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque, Letter of Credit (L/C), Cash Advance (CA), Telegraphic Transfer (T/T), Cash in Advance (CID)

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Digital Universal Testing Machine.

Digital Universal Testing Machine :

This tester was ergonomically designed to provide a compact, low-cost, functional unit which is quick and easy to operate. It gives extremely high accuracy and yet is robust enough for routine quality control testing. The single and twin column designs permit all-round access to the specimen and grips.
The basic frame allows a total jaw seperation of 1000 mm. However, extended frame having jaw seperation upto 2000 mm may be supplied at additional cost.
The machine is operated on 230 volts. 1-ph, 50 c/s. A. C. Mains or as desired.
A comprehensive range of grips, attachments/fixtures, cutting dies are available to suit the testing needs of many different industries.
Capacities available: 20 Kgf to 10000 Kgf

Versatile Material Testing Capabilities

Engineered for versatility, the Digital Universal Testing Machine accommodates both round specimens up to 40 mm and flat specimens up to 30 mm. With adjustable, self-aligning grips and a test range of 0 to 100 kN, it delivers accurate results for various strength of material applications. Programmable test cycles and auto-centering features streamline the testing process, making it ideal for research, quality control, and educational institutions.

Integrated Digital Control and Reporting

This UTM is equipped with digital LCD displays, automated digital/PLC control modes, and user-friendly analysis software. Results are stored in built-in memory and can be exported or reviewed via USB or RS232 interfaces. The inclusion of live data display and instant response time allows operators to monitor tests in real-time, supporting precise and efficient data collection for compliance and reporting.

Enhanced Safety and Certified Accuracy

Safety is paramount with features like overload and overtravel protections, interlocked guards, and emergency stop functions. The high-precision load cell and digital calibration ensure certified accuracy at 1%. Designed for reliable operation in Indian laboratory environments, it supports ambient gas pressure, humidity 80%, and a temperature range of 10C to 35C.

FAQs of Digital Universal Testing Machine.:

Q: How does the Digital Universal Testing Machine ensure accurate and reliable test results?

A: Accuracy is maintained via a high-precision load cell, digital calibration, and certified measurement standards (ASTM, IS, ISO). The machine provides a measuring range between 1% and 100% of its capacity with 1% accuracy and instant response time, ensuring each test result is both precise and reliable.

Q: What is the process for storing and analyzing test data with this UTM?

A: Test data is automatically stored in the units built-in memory during operation. The included analysis and reporting software allows for detailed evaluation, while PC connectivity via USB or RS232 enables easy data export, backup, and advanced analysis to support formal documentation or further research.

Q: When should I perform calibration and how is it managed on this machine?

A: Calibration is required at scheduled intervals based on usage and regulatory guidelines. This UTM features digital, certified calibration methods, which simplify the process and help maintain compliance with international testing standards, ensuring ongoing accuracy for all material strength assessments.

Q: Where can this testing machine be used most effectively?

A: The Digital Universal Testing Machine is suitable for laboratories, educational institutions, industrial quality control, and research centers. Its robust construction and adaptable features make it particularly effective for diverse strength of material testing applications in Indian environments.

Q: What benefits does the automatic centering and adjustable grip system offer?

A: Automatic centering and adjustable, self-aligning grips accommodate a wide range of specimen shapes and sizes, reducing operator intervention and improving test consistency. This ensures optimal alignment during tests, minimizing sample preparation time and enhancing result reliability.

Q: How does the machine maintain operator safety during testing?

A: Operator safety is safeguarded through several measures: interlocked guards prevent access to moving parts, overload and overtravel protection stop the machine if unsafe conditions arise, and an emergency stop button allows immediate shutdown in case of unexpected events.

Digital Universal Testing Machine.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Email

More Products in Strength of Material Testing Equipments Category

Digital Compression Testing Machine for knowing Strength of Material
