Camber Board

Get a Price/Quote

MOQ : 1 Piece

Camber Board Specification

Accuracy
1 mm

Automation Grade
Manual

Specimen Size
Standard Road Surface width

Equipment Type
Camber Board

Temperature
0C to 50C

Product Type
Camber Board

Usage
Bitumen Testing Instruments

Measuring Range
025 mm

Humidity
Up to 80% RH (non-condensing)

Features
Lightweight, Portable, Easy-to-read scale, Durable Body

Resolution
1 mm

Display Type
Graduated Scale

Test Range
025 mm (Camber)

Application
Bitumen Testing Instruments

Response Time
Immediate (manual reading)

Mounting Type
Hand-held/Portable

Machine Weight
Approx 3-5 kg

Test Width
300 mm

Control Mode
Manual

Edge Type
Smooth, non-sharp

Material
Aluminum/Steel

Width
300 mm (approximate)

Length
1 meter (approximate)

Finish
Powder coated / Anodized

Markings Color
Black/Red

Camber Board Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces, , Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Camber Board

Camber Board: MTBA -05

Camber is defined as the slope provided to the cross-section of the road. It expressed as the ratio of the crown height to half the horizontal width of the carriageway for example if the camber is 1 in 45 it means for every horizontal length of 45 m measured from the center of the road towards its edge the rise is of the crown is 1 m it is also expressed as percentage a chamber of 2% means 2 m rise of the crown for 100 m horizontal length of the road in other words 2% camber =2/100 i.e. 1 in 50 it is expressed as the slope of line or the line ration C : b/2 it is also expressed as a percentage.

Features

High quality
Efficient
Durable
The original, arc-shaped profile.
Best for high speeds, carving, stability
Packed, groomed snow, all-mountain
Board has an obvious front & back
Nose easily floats above powder, stiff tail maintains stability at high speeds
Powder, free ride
Flow Infinite
Camber angle (negative angle)
Spindle angle
King pin axis
Scrub radius

Technical Specification

Ratio 2.0%, 2.5%, 3.0% or as per requirement.
Material Aluminum section of size 24 mm x 45 mm of thick gauge.
Size 3 meter, 3.5 meter, 3. 75 meter or as per requirement.
Camber depends on the nature of the road surface and the rainfall in the area
Indian road congress (IRC) has given recommendations for camber of various road surface
Earth road 3% to 4%
Gravel and water bound macadam road 2.5% to 3%
Bituminous road (thin surface) 2% to 3%
Cement concrete and high type bituminous surfaces 2%

Accessories

Magnetic
Spirit level
Seat for it at center

Precision Engineering and Durable Construction

Crafted with high-quality aluminum or steel, this Camber Board provides robust structural integrity for intensive usage. The powder-coated or anodized finishes enhance durability and resist environmental effects, ensuring a long service life for both lab and field applications. Its lightweight body makes it easy to carry and set up wherever required.

User-Friendly Measurement and Accurate Results

Engineered for manual operation, the Camber Board delivers straightforward measurements with a graduated scale, allowing users immediate results with high clarity. With a measurement range of 025 mm and an accuracy of 1 mm, professionals can depend on precise and reliable readings for bitumen testing throughout road maintenance and construction.

FAQs of Camber Board:

Q: How do you operate the Camber Board during bitumen testing?

A: To use the Camber Board, simply place it across the standard road surface width where the camber measurement is required, then manually read the value on the graduated scale within the test range of 025 mm.

Q: What materials are used in manufacturing the Camber Board?

A: The board is constructed from either aluminum or steel, featuring a powder-coated or anodized finish for enhanced durability and resistance to wear and corrosion.

Q: Where is the Camber Board typically utilized?

A: It is commonly used in laboratories and onsite by road construction professionals to measure camber on bitumen road surfaces, helping ensure compliance with quality standards.

Q: What benefits does the Camber Board offer for road surface evaluation?

A: It provides immediate, accurate measurements with a clear, easy-to-read scale. Its lightweight and portable design make it convenient for field assessments, promoting efficient testing and quality assurance.

Q: When should the Camber Board be used in the road testing process?

A: The Camber Board can be used during initial road construction, routine maintenance assessments, and quality control checks to verify proper road camber formation as specified in project standards.

Q: What is the measuring accuracy of the Camber Board?

A: The Camber Board offers an accuracy of 1 mm and a resolution of 1 mm, ensuring reliable and precise measurements of road surface camber.
