THYRISTER / IGBT CONTROLLED AC MOTOR DRIVE WITH VVVF CONTROLS Specification

Number of Specimens
1 motor per test cycle

Automation Grade
Semi-automatic

Display Type
Digital LCD

Humidity
Up to 90% RH

Interface Type
Digital & analog input/output, RS-485

Max Height
300 mm

Operating Voltage
220V / 415V AC

Frequency
50/60 Hz

Power Supply
220V / 415V AC, 50Hz

Port Size
Standard IEC connectors

Mounting Type
Table top/Panel mount

Equipment Type
Thyrister / IGBT Controlled AC Motor Drive with VVVF Controls

Test Range
0.5 kW to 5.5 kW motor capacity

Usage
Thyrister / IGBT Controlled AC Motor Drive with VVVF Controls

Application
Precision control of AC motors in laboratories and industries

Resolution
0.01A / 0.1V

Measuring Range
0 - 300 V, 0 - 20 A (depending on motor)

Features
VVVF, overcurrent and thermal protection, digital display, programmable control

Response Time
< 10 ms

Specimen Size
Universal, customizable clamps

Temperature
Operating: 0C to 50C

Accuracy
1.5%

Capacity
Up to 7.5 HP motors

Machine Weight
45 kg

Test Speed
Variable up to 3000 RPM

Test Width
100 mm

Test Stroke
Adjustable, up to 200 mm

Control Mode
VVVF (Variable Voltage Variable Frequency)

Firmware Upgrade
Field upgradable via serial port

Motor Compatibility
Supports Induction and Synchronous AC motors

Panel Indicators
Power, Fault, Operation status LEDs

Minimum Load
0.5 kW

Protection
Short circuit, overvoltage, and overload protection

Drive Technology
Thyristor/IGBT power semiconductors with microcontroller based controls

Communication Options
Modbus (optional)

Cooling Method
Forced air cooling with built-in fan

Insulation Class
Class F

Input Phase
Single phase/Three phase options available

THYRISTER / IGBT CONTROLLED AC MOTOR DRIVE WITH VVVF CONTROLS Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C)

Packaging Details
Carton Box, Export Quality also Available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001, CE

THYRISTER / IGBT CONTROLLED AC MOTOR DRIVE WITH VVVF CONTROLS About

Thyrister / IGBT Controlled AC Motor Drive with VVVF Controls

Suppliedwith 3 Phase Induction Motor 3HP Fitted with Proximity Sensor & ControlPanel fitted with Necessary Meters & AC Drive etc.

Advanced Drive Technology

This drive employs thyristor and IGBT semiconductor technologies managed by a robust microcontroller. This combination delivers superior precision in controlling motor speed and torque, ensuring optimal performance across a broad range of applications in education and industry.

Safety and Reliability

Integrated protection mechanisms guard against short circuits, overvoltages, and overloads. The drive's advanced cooling system-using a built-in forced air fan-maintains consistent operation even in demanding environments, up to 90% humidity and 50C ambient temperature.

User-Friendly and Flexible Operation

Power, fault, and operation LED indicators provide immediate status feedback, and the digital LCD enables accurate real-time data monitoring. The system supports flexible mounting, field-upgradable firmware, and offers Modbus communication for seamless integration.

FAQ's of THYRISTER / IGBT CONTROLLED AC MOTOR DRIVE WITH VVVF CONTROLS:

Q: How does the VVVF control enhance the performance of AC motors in this drive system?

A: VVVF (Variable Voltage Variable Frequency) control enables precise adjustment of both voltage and frequency supplied to the motor, allowing for smooth acceleration, deceleration, and stable operation. This ensures optimal efficiency and performance tailored to the specific requirements of different motor types and applications.

Q: What types of motors are compatible with the Thyristor/IGBT Controlled AC Motor Drive?

A: The drive is compatible with both induction and synchronous AC motors, making it versatile for various educational and industrial settings involving different AC motor technologies.

Q: When should I perform a firmware upgrade, and how is it carried out?

A: Firmware upgrades are recommended whenever new features or security enhancements are released. The process is straightforward-connect via the serial port and follow the provided upgrade instructions to ensure the system remains up-to-date and functional.

Q: Where can the drive system be installed, and what are the mounting options?

A: The drive can be conveniently installed either as a table-top unit or as a panel-mounted device, offering flexibility to fit laboratory benches or industrial control panels according to your workspace requirements.

Q: What protective features are included to safeguard the drive and connected motors?

A: Comprehensive protections against short circuits, overvoltages, and overloads are integrated into the drive. In addition, thermal protection and overcurrent safeguards help maximize equipment lifespan and operational reliability.

Q: How is cooling achieved in this motor drive, and why is it important?

A: The system uses a forced air cooling method with a built-in fan to maintain optimal internal temperatures. Effective cooling is essential to prevent overheating, ensuring consistent performance and long-term durability even in high-demand environments.

Q: What are the benefits of digital LCD and status LEDs on this control drive?

A: The digital LCD provides precise readouts for electrical parameters and system status, while power, fault, and operation LEDs offer immediate visual indicators. These features streamline operation, troubleshooting, and monitoring for users.
