About SPEED CONTROL OF DC SHUNT MOTOR BY WARD LEONARD METHOD.

Speed Control of DC Shunt Motor by Ward Leonard Method.

Suppliedwith 3 Phase AC Induction Motor 2HP Coupled with DC Shunt Generator 1KW, DCShunt Motor 0.5HP, Control Panel fitted with Necessary Meters & DOL Starteretc.



Advanced Speed Control Demonstration

This system allows students and professionals to explore variable speed control of DC shunt motors using the acclaimed Ward Leonard method. With a seamless coupling of AC motor, DC generator, and DC motor, the apparatus demonstrates precise speed variations from 0 to 1500 RPM.


Robust Construction & Safety Emphasis

Built with a powder-coated metal body, high-quality terminals, and fuse protection, the equipment ensures longevity and operator security. The emergency stop and indicator-equipped control panel enhance safe usage during experiments and teaching demonstrations.


User-Friendly Digital Interface

The system features a digital RPM indicator with 1% accuracy, enabling real-time, high-resolution speed monitoring. Clearly laid-out terminal connections and a demo panel with a circuit diagram simplify understanding and operation.

FAQ's of SPEED CONTROL OF DC SHUNT MOTOR BY WARD LEONARD METHOD.:


Q: How does the Ward Leonard method control the speed of a DC shunt motor in this equipment?

A: The Ward Leonard method uses an AC motor to drive a DC generator, which in turn supplies variable voltage to the DC shunt motor. By adjusting the generator's output, users can finely control the motor speed from 0 to 1500 RPM, providing smooth closed-loop operation.

Q: What are the key benefits of using this system for speed control demonstrations?

A: This setup offers accurate and instantaneous speed adjustments with a resolution of 1 RPM. The integrated safety features and digital RPM display ensure reliability, making it ideal for lab experiments and technical education.

Q: Where is this speed control system typically deployed?

A: The equipment is primarily used in technical institutes, engineering colleges, laboratories, and training centers across India, providing hands-on experience in the Ward Leonard speed control technique.

Q: What protective features are included for operator safety?

A: Safety is prioritized with fuse protection, an emergency stop button, and a metal enclosure. Indicators on the control panel provide operational status, ensuring user security during testing.

Q: How is the system operated and monitored?

A: Operation is manual, featuring easy-to-access terminals and a clear circuit diagram panel. The digital display offers direct RPM readings, and speed control is adjusted via the generator under supervision.

Q: What is the testing and measuring capacity of the unit?

A: This unit accommodates one standard DC shunt motor of 1 HP (0.75 kW), allowing variable speed tests from 0-1500 RPM, measured with 1% accuracy and a digital RPM resolution of 1 RPM.
