SAND GAUGE CHART
SAND GAUGE CHART
images Send Inquiry
Request To Call Back

SAND GAUGE CHART

Get a Price/Quote
MOQ : 1 Piece

SAND GAUGE CHART Specification

  • Usage
  • Civil Engineering Lab Equipments
  • Humidity
  • Ambient
  • Features
  • Graduated color printed chart with plastic envelope for protection
  • Power Supply
  • Not required (manual chart)
  • Test Range
  • 0.05 mm to 2.00 mm sand size
  • Application
  • Civil Engineering Lab Equipments
  • Temperature
  • Room Temperature
  • Max Height
  • Approx. 27 cm
  • Display Type
  • Printed Gauge/Chart
  • Mounting Type
  • Handheld or tabletop
  • Product Type
  • SAND GAUGE CHART
  • Response Time
  • Immediate (manual reading)
  • Measuring Range
  • 0.05 mm to 2.00 mm
  • Equipment Type
  • SAND GAUGE CHART
  • Resolution
  • 0.05 mm increments
  • Automation Grade
  • Manual
  • Number of Specimens
  • Multiple graduations for different grain sizes
  • Accuracy
  • Graduated as per IS: 383
  • Machine Weight
  • 1 kg (approx.)
  • Test Speed
  • Manual operation
  • Test Width
  • Standard chart size, approx. 21 cm
  • Control Mode
  • Manual
  • Protective Cover
  • Plastic sleeve/envelope included
  • Primary Use
  • Determination of sand particle size distribution visually
  • Surface Finish
  • Smooth printed finish
  • Lifespan
  • Long lasting under normal lab conditions
  • Color Coding
  • Color bands for representation of sand sizes
  • Construction Material
  • Durable printed synthetic or coated paper sheet


SAND GAUGE CHART Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Payment Terms
  • Letter of Credit (L/C), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)
  • Supply Ability
  • 100 Pieces Per Week
  • Delivery Time
  • 1 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • carton box, export quality also available
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, 14001 ,CE


SAND GAUGE CHART About

SAND GAUGE CHART

Use: A unique chart for uniform classification of sands.

Standards

  •  To classify soils to BS 1377:2, ENV 1997-2, ASTM D4318, AASHTO T89

Specifications:

  •  Nine granule patches firmly attached to the handy water-resistant plastic card defining roundness and size of particles from 2mm very coarse sand to 1/16mm silt.
  •  A checklist defining bed thickness.
  •  Flip side of chart with tables of geologic age and carbonate classification information.
  •  Sample Panels. Very coarse; coarse; medium; fine; very fine; silt.
  •  Particle Shape Panels. Angular; sub-angular; sub-rounded and rounded.



Visual Precision in Sand Sizing

Sand Gauge Chart delivers accurate identification of sand granules within the 0.05 mm to 2.00 mm range. Its color-coded bands and clearly marked graduations support reliable, rapid visual analysis, which is vital for various construction quality checks in civil engineering labs.


Durable Design for Laboratory Use

This chart is crafted from high-quality printed synthetic or coated paper and is shielded by a plastic cover, ensuring extended service life even with regular handling. The smooth finish and standardized size (approximately 21 cm width, up to 27 cm height) enable effortless tabletop or handheld examination.


Manual, Immediate Results

Completely manual in operation, the Sand Gauge Chart eliminates the need for power or special conditions. Simply position your sample, match the granule sizes, and receive immediate, accurate readings according to IS: 383 standards. The charts fast, straightforward process optimizes testing efficiency.

FAQs of SAND GAUGE CHART:


Q: How is the Sand Gauge Chart used in a civil engineering laboratory?

A: To use the Sand Gauge Chart, place a sand specimen against the charts graduated and color-coded bands. Visual comparison reveals particle sizes, allowing you to determine the sands size distribution quickly and in accordance with IS: 383 standards.

Q: What benefits does the Sand Gauge Chart offer over digital instruments?

A: The Sand Gauge Chart is immune to power failures, offers immediate readings, and requires no calibration. Its manual design is low-maintenance, durable, and perfectly suited for reliable use in ambient lab settings without electricity.

Q: When should the Sand Gauge Chart be utilized?

A: This chart should be used whenever there is a need to visually assess and verify sand particle size distributions for quality control or experiment preparation in civil engineering laboratories.

Q: Where can the Sand Gauge Chart be mounted or placed during tests?

A: It is versatile and can be either handheld or used on any standard laboratory tabletop, providing convenience during sand size analysis without restrictions on workspace requirements.

Q: What process should be followed for the best results with this chart?

A: For optimal accuracy, make sure the sand sample is dry and clean. Place it on the chart under good lighting, and visually align particles with the closest color-coded size bands for precise categorization.

Q: Why is color coding important on the Sand Gauge Chart?

A: The color bands help users quickly differentiate sand granule sizes, reducing chances of misreading and streamlining the analysis process, especially when evaluating multiple grain sizes.

Q: What is the expected longevity of the Sand Gauge Chart under typical laboratory conditions?

A: With its protective plastic cover and durable printed finish, the chart is designed to last for long periods when handled properly in normal laboratory conditions.
