RIPPLE FACTOR APPARATUS WITH BAKELITE PANEL & ROUND METERS (HALF WAVE,FULL WAVE AND BRIDGE RECTIFIER)

Price 1000.0 INR/ Piece

Get a Price/Quote
MOQ : 1 Piece

RIPPLE FACTOR APPARATUS WITH BAKELITE PANEL & ROUND METERS (HALF WAVE,FULL WAVE AND BRIDGE RECTIFIER) Specification

  • Voltage
  • 220 Volt (v)
  • Accuracy
  • 99.9 %
  • Product Type
  • RIPPLE FACTOR APPARATUS WITH BAKELITE PANEL & ROUND METERS (HALF WAVE,FULL WAVE AND BRIDGE RECTIFIER)
  • Application
  • lab
  • Material
  • Mild Steel
  • Usage
  • lab
  • Color
  • White
  • Power
  • 220 Volt (v)
  • Power Supply
  • Electric
  • Frequency
  • 50 Hertz (HZ)


RIPPLE FACTOR APPARATUS WITH BAKELITE PANEL & ROUND METERS (HALF WAVE,FULL WAVE AND BRIDGE RECTIFIER) Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • Packaging Details
  • Carton Box, Export Quality also Available
  • Main Export Market(s)
  • Asia, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001, 14001, CE


About RIPPLE FACTOR APPARATUS WITH BAKELITE PANEL & ROUND METERS (HALF WAVE,FULL WAVE AND BRIDGE RECTIFIER)

Ripple factor Apparatus With Bakelite Panel & Round Meters (Half Wave,full wave and Bridge rectifier)

Instrument comprises of AC Power Supply, 2 meters to measure Output Voltage & Output current, 4 PN Junction Diodes, Filter Circuit Kit, load Resistances selectable using band switch. One dual range Electronic voltmeter to measure ripple directly.




Comprehensive Rectifier Analysis

This apparatus is tailored for studying the performance of different rectifier circuits, allowing students and professionals to observe ripple factor, voltage, and current across half wave, full wave, and bridge configurations. Its round meters and durable mild steel body ensure accurate measurement and long-term usability, making it indispensable for any electrical or electronics laboratory.


Built for Laboratory Efficiency

The rippling factor apparatus is constructed with a robust white Bakelite panel and mild steel, providing excellent insulation and mechanical strength. Easy-to-read meters and reliable components facilitate straightforward operation and effective learning or demonstration sessions within academic institutions and research centers.

FAQs of RIPPLE FACTOR APPARATUS WITH BAKELITE PANEL & ROUND METERS (HALF WAVE,FULL WAVE AND BRIDGE RECTIFIER):


Q: How does the Ripple Factor Apparatus help in studying rectifier circuits?

A: The apparatus allows students and engineers to analyze how different rectifier circuitshalf wave, full wave, and bridgefilter and smooth electrical signals. It demonstrates the ripple content after rectification, enabling users to measure efficiency and performance of each configuration.

Q: What is the process of using the Ripple Factor Apparatus in a laboratory?

A: To use the apparatus, connect the input supply (220V, 50Hz) and select the desired rectifier circuit. Measure the output using the round meters provided, and record the resulting voltage and ripple factor for analysis. Its practical construction ensures safe and repeatable experiments.

Q: When should this apparatus be used during electrical studies or experiments?

A: This device is most beneficial for laboratory sessions involving rectifiers, electrical circuit analysis, or demonstrations on power conversion and filtering. It can be integrated into both theoretical learning and hands-on courses involving power electronics.

Q: Where is the Ripple Factor Apparatus commonly used?

A: It is widely employed in academic institutions, research laboratories, technical training centers, and industrial training workshops across India for educational and analytical purposes.

Q: What benefits does the Bakelite panel provide to the apparatus?

A: Bakelite is an excellent insulator and is heat-resistant, ensuring user safety during experiments. Its sturdy panel also enhances durability and protects the internal apparatus, making it suitable for repeated laboratory use.

Q: Is this apparatus suitable for exporting and supplying to institutions outside India?

A: Yes, the apparatus is designed for exporting and supplying globally. As per the distributor, exporter, manufacturer, and supplier listings, it meets quality and safety standards required for international educational and industrial applications.
