Orifice And Jet Velocity Apparatus

Price 100 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Orifice And Jet Velocity Apparatus Specification

Automation Grade
Manual

Product Type
Orifice And Jet Velocity Apparatus

Port Size
Inlet: inch BSP

Response Time
Instantaneous (manual visual observation)

Measuring Range
Velocity and discharge measurement

Resolution
1 mm in measuring scale

Humidity
Up to 85% RH

Accuracy
1% of full scale

Specimen Size
Orifice diameter: 6 mm, 8 mm, 10 mm

Frequency
50 Hz

Features
Interchangeable orifices, clear acrylic tank, adjustable jet set-up, measurement scale

Equipment Type
Orifice And Jet Velocity Apparatus

Max Height
Approx. 1.0 m (apparatus assembly)

Application
Fluid Machines Equipments

Mounting Type
Floor mounted

Operating Voltage
230 V AC

Usage
Fluid Machines Equipments

Number of Specimens
Single specimen test

Temperature
Operating up to 45C

Test Range
For various orifice sizes and jet velocities

Power Supply
230 V AC, 50 Hz

Display Type
Graduated scale/mechanical

Capacity
Water tank capacity approx. 40 liters

Machine Weight
Approximately 45 kg

Control Mode
Manual

Orifice And Jet Velocity Apparatus Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Orifice And Jet Velocity Apparatus

Orifice And Jet Velocity Apparatus:

Micro Teknik are offering Orifice and Free Jet Flow A plexiglas cylinder is equipped with an adjustable overflow and scale which enables the height of the water column to be set and read accurately. 2 types of outlet nozzle can be compared. The trajectory of the jet can be traced using adjustable probes and recorded on a white panel.

The water supply is provided either from the laboratory mains or using the HM 150 (closed water circuit).

Learning Objectives / Experiments

Discharge coefficient from nozzles of varying sizes and shapes
Trajectory of the water jet for various discharge velocities
Effect of the height of the water column on discharge velocity

Specification
[1] Unit for investigating the discharge from nozzles, for use with the HM 150
[2] Draining of a water-filled Plexiglass cylinder through a nozzle
[3] Cylinder with adjustable overflow and scale
[4] 2 exchangeable nozzles
[5] 8 tracers and white panel to record the jet trajectory

Superior Measurement and Observation

Featuring a clear acrylic tank and a scale for direct jet trajectory measurement, the apparatus enables precise visual and manual observation of water jets produced by interchangeable orifices. Adjustability of the jet set-up and high-resolution scale (1 mm) further enhance measurement accuracy and repeatability.

Robust Design and Safety

Built with a sturdy support structure, non-return valve, and reliable ball valve drain arrangement, the equipment ensures safe operation in educational settings. It is floor-mounted and constructed from durable stainless steel/aluminium and acrylic, contributing to its long-lasting performance under frequent usage.

Flexible and Manual Operation

The manual control mode allows direct manipulation and adjustment during experiments, while the integrated graduated scale ensures instantaneous readings. Power is supplied via a standard 230 V AC connection for hassle-free integration into laboratories. Optional accessories such as stopwatches and additional orifices expand the scope of experimentation.

FAQs of Orifice And Jet Velocity Apparatus:

Q: How is jet velocity measured using the Orifice and Jet Velocity Apparatus?

A: Jet velocity is measured by observing the water jets trajectory using the attached graduated scale. The apparatus allows for instantaneous manual visual readings, with a resolution of 1 mm to ensure accuracy during experiments.

Q: What materials are used in the construction of the apparatus?

A: The apparatus is constructed from stainless steel or aluminium for structural components, and clear acrylic is used for the tank and fittings. These materials offer durability, resistance to corrosion, and enable clear observation of fluid flow.

Q: When should the apparatus be used in the laboratory setting?

A: It is best deployed during demonstrations, teaching sessions, or research activities related to fluid mechanics, especially when investigating fluid discharge, jet velocities, and orifice effects in educational labs or research facilities.

Q: Where is the apparatus installed and how much space does it require?

A: The Orifice and Jet Velocity Apparatus is floor-mounted, requiring a space of approximately 1000 mm x 500 mm x 1200 mm. Its compact footprint makes it suitable for a variety of laboratory environments.

Q: What is the process for conducting experiments with different orifice sizes?

A: Users can interchange the orifice sets (6 mm, 8 mm, 10 mm) to observe how different diameters affect jet velocity and discharge. Setup involves filling the acrylic tank (approx. 40 liters), operating the centrifugal pump, and using the scale to record measurements for each configuration.

Q: How does using this apparatus benefit students and researchers?

A: The apparatus provides hands-on learning and real-time measurement opportunities, fostering deeper understanding of fluid mechanics principles. Its accuracy, immediate response time, and clear visualization of the jet trajectory make experimental observations accessible and reliable for both demonstration and research purposes.
