Microprocesser Fribility Test Apparatus

Microprocesser Fribility Test Apparatus

Send Inquiry

Request To Call Back

Microprocesser Fribility Test Apparatus

Get a Price/Quote

MOQ : 1 Piece

Microprocesser Fribility Test Apparatus Specification

Capacity
Single Drum / Double Drum Optional

Core Components
Microprocessor, Motor, Acrylic Drum

Measurement Range
1 to 999 revolutions

Temperature Range
Ambient

Model No
MFTA-2591824

Power Source
230V AC Mains

Accuracy
1 revolution

Application
Pharmaceutical Lab Equipment

Product Type
Microprocesser Fribility Test Apparatus

Voltage
230 V AC

Frequency
50 Hz

Feature
Programmable Test Time, Automatic Stop

Automation Grade
Fully Automatic

Usage
Pharmaceutical Lab Equipment

Equipment Materials
Stainless Steel Body, Acrylic Drum

Type
Microprocessor Controlled

Display Type
Digital LCD Display

Dimension (L*W*H)
290 x 210 x 220 mm

Weight
Approx. 8 Kg

Timer
Programmable Digital Timer

Compliance
IP/BP/USP Specifications

Number of Samples
Up to 10 Tablets Per Test

Cleaning
Removable drum for easy cleaning

Drum Material
Acrylic

Drum Size
Diameter 100 mm x Length 25 mm

Test End Indication
Audio-Visual

Speed Accuracy
1 RPM

Microprocesser Fribility Test Apparatus Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
No

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Microprocesser Fribility Test Apparatus

Microprocesser Fribility Test ApparatusMeasures the tendency of tablet to chip or breakdown to pieces when held under mechanical stress. Instrument uses the latest microcontroller technology and advanced engineering techniques so as to give enhanced accuracy and reproductibility Instument is equipped with 4 line alphanumeric LCD display with backlit and 16no of soft touch membrane type keys.
Friability tester can be operated using only one or two drums. The rotational speed of drums can be set at different speeds (20-60rpm). The samples can be loaded conveniently without removing the drums and after the test completion the samples are automatically unloaded to the collectionn tray. To eliminate the manual input of weight of samples, the facility of connecting a weighing scale is also available. When weighing scale is connected the weight of sample is automatically recorded to the instrument from weighing balance.
The test can be performed in two different modes Time or Count mode. The instrument stores the test parameters, readings and results simultaneously inn the memory which are retained even after the power is switched off. Provision is also been made for attachment of a printer so as to provide hardcopy printouts of test data, including time, date and calculated results.
Specification:
Test Methods : Time Count Mode.
Speed Of Drums : 20-60 RPM.
No Of Drums : 2.
Display : 20x4 Alphanumeric Lcd.
Keyboard : Soft Touch Membrane Keys, Alphanumeric Mobile Keypad.
Counter : 1 TO 9999 Rotations.
Timer : 1 SEC TO 9HRS 59MIN 59 SECS.
Type Of Drive : Direct Drive With Stepper Motor.
Printer : Attachment Of RS232 Printer With Serial Interface.
Electrical Supply : 230V AC 10%, 50/60HZ, 44VA.
Advantages :

Microprocessor based, easy to use.
Complies with USP, IP Specifications.
20 x 4 line alphnumeric LCD display with backlit.
16 soft touch membrane type keys.
Independent programmable setups for Time Count mode with storage.
Password protected user access.
RS232 printer attachment facility.
Automatically calculates percentage friability.
Loading and unloading of tablets without removing drums.
Power failure detection facility.
User friendly operation with menus current status indicators.

Advanced Microprocessor Control

The apparatus is fully automated and integrates a sophisticated microprocessor for precise operation. Test parameters are programmable, allowing users to set the desired time (1999 revolutions) and benefit from automatic stop features. This technology guarantees accuracy, uniformity, and reproducibility in every test cycle.

Designed for Laboratory Efficiency

With a capacity for up to 10 tablets per test and options for single or double drum operation, this instrument streamlines workflows in busy pharmaceutical labs. Its construction from stainless steel and acrylic ensures durability, while a removable drum simplifies post-test cleaning.

User-Friendly Display and Indication

Equipped with a bright digital LCD display, the apparatus ensures easy setting and monitoring of test parameters. The audio-visual indication feature notifies users immediately when tests conclude, optimizing both safety and productivity.

FAQs of Microprocesser Fribility Test Apparatus:

Q: How does the Microprocessor Friability Test Apparatus operate?

A: This apparatus uses a microprocessor to control all test parameters. The user sets the required number of revolutions or test duration using the digital LCD display. Once initiated, the drum (made of acrylic) rotates at an accurate speed (1 RPM), and the device automatically stops after the programmed test time, providing an audio-visual indication when complete.

Q: What types of tablets can be tested with this apparatus?

A: It is suitable for friability testing of compressed pharmaceutical tablets in compliance with IP, BP, and USP standards. The drum accommodates up to 10 tablets per cycle, making it ideal for routine quality control in research and manufacturing labs.

Q: When should the drum be cleaned, and how is this done?

A: The removable acrylic drum should be cleaned after each test cycle or whenever a different batch of tablets is tested to ensure accuracy. Simply detach the drum from the apparatus, wash it with suitable cleaning agents, and reinstall it before the next use.

Q: Where is this friability tester typically used?

A: Designed for pharmaceutical laboratories, the apparatus is commonly found in research facilities, quality control departments, and educational institutions related to pharmaceutical sciences.

Q: What benefits does the programmable digital timer provide?

A: The programmable digital timer allows precise setting of test duration or revolution count (from 1 to 999), ensuring tests are performed exactly to protocol. It minimizes human error, saves time, and improves the reliability of results.

Q: How does the audio-visual test end indication enhance usage?

A: The audio-visual indication feature alerts users immediately upon completion of the test, reducing the need for constant monitoring and preventing over-testing, which could compromise results.
