Laser Optics Box 5 Beams

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 13 Pieces

Laser Optics Box 5 Beams Specification

Accuracy
Precision aligned laser beams

Core Components
Laser diode, optical glass, holders, mirror assembly

Application
General lab equipments

Feature
Demonstrates basic optics principles with 5 separate laser beams

Voltage
Typically 220V AC or 12V DC, depending on model

Temperature Range
Ambient laboratory conditions

Automation Grade
Manual

Product Type
Laser Optics Box 5 Beams

Capacity
5 beams

Power Source
Mains or battery powered (varies by model)

Usage
General lab equipments

Model No
LOB-5

Equipment Materials
Plastic and metal housing with optical-quality glass components

Type
Laser Optics Box

Dimension (L*W*H)
Approx. 320 mm x 290 mm x 60 mm

Weight
Approx. 800 grams

Laser Optics Box 5 Beams Trade Information

Minimum Order Quantity
13 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Laser Optics Box 5 Beams

Laser Optics Box 5 Beams

Complete with 1 laser 5 beams
Very visual in daylight thanks to the laser multibeam
Size suitable for experiments raises on the table
Many possible experiments by combining the optical components Red laser with switch to generate
1, 3 or 5 rigorously parallel beams.
Horizontal use with supplied plexiglass optics accessories.

Composition:

1 Laser class II (1 mW): 1, 3 or 5 beams powered by 1 x 6.3 V mains adapter
1 mat with graduated disc in degree and ruler in mm, 210 x 380 mm
1 graduated disc150 mm, 1 rectangle prism
1 flexible mirror (flat, concave or convex), 1 parallel-faced plate
1 hemicylindrical lens
1 biconvex lens
1 biconcave lens
1 hemicylindrical tank
1 trapeze
Supplied in an aluminum storage case
Dimensions: 280 x 70 x 240 mm.

Precision and Safety in Optics Education

With five individually aligned beams and low divergence, the Laser Optics Box offers accurate demonstrations of core optics principles. Its red laser beamssafe at under 1 mW (Class 2)enable students and technicians to explore ray paths, reflection, and refraction confidently. Designed to withstand standard laboratory conditions, this unit ensures consistent results without compromising on user safety.

Comprehensive Accessories and Flexible Power Options

The box comes equipped with essential accessories such as beam shields, adjustable mounts, and a detailed instruction manual. Depending on the model, it operates either on mains electricity (220V AC) or 12V DC battery, making it adaptable for various laboratory setups or mobile educational demonstrations.

Robust and User-Friendly Design

Constructed with durable plastic and metal and featuring optical-grade glass components, the devices compact structure (approx. 320 mm x 290 mm x 60 mm) and manageable weight (around 800 grams) make it both resilient and easy to handle. Manual operation allows for straightforward adjustments, supporting a wide range of instructional and experimental needs.

FAQs of Laser Optics Box 5 Beams:

Q: How do I set up the Laser Optics Box 5 Beams for laboratory use?

A: To set up the box, simply position it on a stable, flat surface in your laboratory, connect it to the appropriate power source (220V AC or 12V DC, depending on the model), and use the provided adjustable mounts and beam shields as needed. The instruction manual guides you through safe installation and alignment.

Q: What applications is the Laser Optics Box suitable for?

A: This equipment is ideal for demonstrating and studying basic optics principles such as ray tracing, reflection, refraction, and beam behavior. It is suitable for general laboratory experiments, educational demonstrations, and optical training activities.

Q: When should I use the included beam shields and mounts?

A: Beam shields and mounts should be used whenever you want to direct, block, or adjust the paths of the individual laser beams, especially during demonstrations or experiments. They enhance safety and precision during operation.

Q: Where can the Laser Optics Box be effectively used?

A: It is designed for use in general laboratory environments, including classrooms, university labs, and research facilities. The operating temperature range (0C to 40C) fits most ambient laboratory conditions.

Q: What safety features does this laser optics box have?

A: The product operates at less than 1 mW laser power for eye safety, is categorized as a Class 2 Laser Product, and comes with beam shields to minimize exposure. The low-divergence beams further reduce risks during hands-on demonstrations.

Q: How does the Laser Optics Box benefit optical experiments and instruction?

A: By offering five precisely aligned laser beams, the box enables simultaneous experimentation with multiple beam paths, supporting in-depth understanding of optics principles. Its accurate and stable performance enhances the educational experience and experimental repeatability.
