Laboratory Vane Shear Apparatus

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1 , , Piece

Laboratory Vane Shear Apparatus Specification

Feature
Portable, Easy operation, Precise measurements

Capacity
2 kg/cm

Power Source
Manual

Product Type
Laboratory Vane Shear Apparatus

Application
Soil Testing Equipments

Frequency
50 Hz

Measurement Range
0-2 kg/cm

Voltage
Not required (manual)

Accuracy
0.01 kg/cm

Usage
Soil Testing Equipments

Automation Grade
Manual

Temperature Range
Ambient

Model No
Lab-VS-100

Core Components
Vane, Torque Applicator, Container, Base, Handle, Dial Indicator Gauge

Equipment Materials
Mild Steel with powder coating

Type
Manual Operated

Display Type
Analog Dial Gauge

Dimension (L*W*H)
Approx. 420 x 320 x 500 mm

Weight
Approx. 12 kg

Laboratory Vane Shear Apparatus Trade Information

Minimum Order Quantity
1 , , Piece

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Laboratory Vane Shear Apparatus

Laboratory vane shear app. Hand operated:

Specifications:

Consists of a torque head adjustable in height by means of a lead screw rotated by a drive wheel to enable the vane to be lowered into the specimen.
Rotating of the vane is by means of a hand wheel which operates a worm gear arrangement during upper end of calibrated torsion spring.
Vane dia, rod dia, vane size & vane height as per IS specifications. The Vane Shaft is attached through the hollow upper shaft to a resetable pointer, which indicates the angle of torque on a dial graduated in degrees. The dial reading multiplied by spring factor gives the torque. A container for soil sample is also supplied, and a sampling tube of 38mm I.D. & 150mm long can also be used as container.
Supplied with set of four springs, one each of approx. 2 kg.cm., 4 kg.cm., 6 kg.cm., and 8 kg.cm. Complete as above in a wooden carrying case.

Precision Soil Shear Strength Measurement

Engineered for rigorous soil analysis, the Lab-VS-100 delivers accurate shear strength data through its finely graduated analog dial gauge. With a robust vane size and precise torque application, the apparatus enables repeatable results essential in geotechnical investigations.

Durable and Corrosion-resistant Design

Constructed from powder-coated mild steel, the apparatus withstands demanding laboratory conditions and frequent field use. Its corrosion-resistant finish ensures longevity and minimal maintenance, making it a cost-effective solution for routine soil testing.

User-Friendly Manual Operation

Designed for ease of use, the manual mechanism avoids reliance on electrical sources, allowing convenient operation in a range of environments. The apparatuss portability and straightforward assembly enhance its practical value for diverse soil testing scenarios.

FAQs of Laboratory Vane Shear Apparatus:

Q: How is soil shear strength measured using the Laboratory Vane Shear Apparatus?

A: Soil shear strength measurement is accomplished by inserting the vane into the soil sample and manually rotating the handle at a controlled speed of 1 revolution per minute. The dial indicator gauge records the maximum torque applied until the soil fails, which corresponds to the maximum shear stress (up to 2 kg/cm).

Q: What are the main benefits of the Lab-VS-100 for soil testing laboratories?

A: The main benefits include portable design, corrosion-resistant powder coating, and high measurement accuracy (0.01 kg/cm). Its manual operation requires no electricity, making it suitable for both laboratory and field applications, and its easy-to-read analog dial gauge ensures precise results.

Q: When should the Laboratory Vane Shear Apparatus be used in geotechnical assessments?

A: This apparatus is ideal when determining the undrained shear strength of cohesive soils, particularly during initial site evaluations, foundation investigations, or quality control in construction projects where soil stability analysis is essential.

Q: Where can the Lab-VS-100 be effectively utilized?

A: The Lab-VS-100 can be used in academic research laboratories, geotechnical engineering firms, construction material testing labs, and on-site field investigations across India, especially where portable, power-independent equipment is advantageous.

Q: What is the process for preparing a soil sample for shear measurement?

A: A representative soil sample is placed in the 1-liter container, ensuring uniformity and eliminating air pockets. The vane is positioned vertically into the sample, and then the torque applicator is used to rotate the vane while the dial gauge measures the shear stress exerted before soil failure.

Q: How does the apparatus maintain measurement accuracy in varying ambient temperatures?

A: The Lab-VS-100 is engineered to operate efficiently at ambient temperatures up to 45C. Its mechanical construction and corrosion-resistant materials ensure reliable and consistent performance with minimal interference from temperature fluctuations.
