Geneva Drive

Get a Price/Quote

MOQ : 1 Piece

Geneva Drive Specification

Features
Intermittent Motion Mechanism, Study Model

Application
Mechanism Models

Equipment Type
Demonstration Mechanism

Product Type
Geneva Drive

Automation Grade
Manual

Mounting Type
Tabletop

Max Height
Approx. 160 mm

Usage
Mechanism Models

Machine Weight
1.6 kg

Control Mode
Manual

Drive Type
Geneva Wheel

Rotary Input Handle
Provided

Input Shaft Material
Mild Steel

Finish
Powder Coated

Number of Stops
4 (can be customized)

Demonstration
Intermittent Rotary Motion

Color
Silver & Blue

Material
Mild Steel and Acrylic

Output Wheel
Acrylic

Base Dimensions
Approx. 250 mm x 120 mm

Geneva Drive Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Telegraphic Transfer (T/T), Cheque, Letter of Credit (L/C), Cash in Advance (CID), Cash Advance (CA)

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Geneva Drive

Discover the trending Geneva Drive model, meticulously crafted with a noble combination of mild steel and pristine acrylic. Designed for the best price, this demonstration mechanism features a crowning powder-coated finish in elegant silver and blue. With four customizable stops and intermittent rotary motion, its ideal for mechanism studies. The redeeming value of this manual, tabletop device is unmatched, and its compact buildmeasuring approximately 250 mm x 120 mm and weighing just 1.6 kgmakes it suitable for laboratory or educational use. Supplied by Indias leading distributor, exporter, manufacturer, supplier, and trader.

Geneva Drive: Features, Uses, and Application Sites

The Geneva Drive is often used in mechanism model demonstrations within educational institutions and mechanical labs. Its intermittent motion mechanism makes it ideal for simulating index systems and automatic machinery. Distinguished features include a durable powder-coated finish, manual rotary input, and customizable stops. It can be used as a study model or demonstration unit to illustrate the principles of intermittent movement. This pristine device securely mounts to tabletops, catering perfectly to teaching, experimentation, and functional display.

Geneva Drive: Secure Shipping, Delivery, and Export Information

Valuation for Geneva Drive is competitive, and secure shipping is ensured for international deliveries. The standard FOB port is located in India, enabling streamlined global distribution. The main export markets include Asia, the Middle East, and Africa, with reliable partners handling logistics. Sample policy allows for tailored sample provision under specific terms, ensuring that clients can assess machine quality before full order commitment, guaranteeing satisfaction and seamless delivery to your location.

FAQs of Geneva Drive:

Q: How do you operate the Geneva Drive demonstration mechanism?

A: The Geneva Drive operates manually using the provided rotary input handle. By turning the handle, the mild steel input shaft drives the acrylic output wheel to generate intermittent rotary motion, ideal for demonstration purposes.

Q: What are the main applications for the Geneva Drive?

A: The Geneva Drive is primarily applied in educational settings, laboratories, and engineering demonstrations to study intermittent motion and indexing systems. Its accuracy and customizable stops make it a valuable teaching and modeling tool.

Q: Where is the Geneva Drive typically mounted during demonstrations?

A: This model is designed for mounting on tabletops, ensuring stability and ease of use during demonstrations in classrooms, training sessions, or laboratories.

Q: What is the process for customizing the number of stops in this mechanism?

A: Customizing the number of stops involves adjusting the Geneva Wheel to include more or fewer slots. The standard model comes with four stops, but customization is available upon request to suit specific demonstration needs.

Q: When should you consider using a Geneva Drive in your mechanism models?

A: A Geneva Drive should be considered when an intermittent motionsuch as indexing, timing, or controlled rotationis required within mechanism models or instructional demonstrations.

Q: What benefit does the acrylic output wheel provide?

A: The acrylic output wheel offers smooth movement, clear visibility of motion for demonstration purposes, and an impactful visual contrast against the mild steel and powder-coated base.
