Free Fall With Digital Displays

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Free Fall With Digital Displays Specification

Product Type
Free Fall With Digital Displays

Model No
FFDD-01

Frequency
50 Hz

Temperature Range
Ambient to 50C

Voltage
220-240 V AC

Feature
Precise free fall timing, Digital Read Out, Safety Interlock

Power Source
Electric

Automation Grade
Semi-Automatic

Capacity
1 to 5 kg

Usage
General Lab Equipments

Core Components
Sensor, Digital Display, Power Supply Unit

Accuracy
0.1 ms

Measurement Range
0.01s to 9.99s

Application
General Lab Equipments

Equipment Materials
Stainless Steel, Mild Steel, Glass, Acrylic

Type
Lab Equipment

Display Type
Digital

Dimension (L*W*H)
500 x 300 x 500 mm (approx.)

Weight
15-22 kg (approx.)

Free Fall With Digital Displays Trade Information

Minimum Order Quantity
1 Piece

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Free Fall With Digital Displays

Free Fall With Digital Displays

With 4 forks with digital display.
Simultaneous measurement and display of time and speed for 2 or 4 positions of the ball.
Very quick and easy to install.
The optical forks with digital display simultaneously measure the duration of the drop and speed at each position on the graduated rail. Each fork can memorize 5 measured values.
The first fork sees the passage of the ball when released and triggers the timing of the other forks.
The rail provides power and communication between all the forks.
To multiply the measuring points, the forks can slide along the graduated rail.
It is also possible to supplement with other optical forks with digital display to install on the rail, to increase the number of simultaneous measuring points.
Each optical fork with digital display is removable and can also be used alone to measure, for example, the speed of a mobile.

Technical data

Time measurement at 1/10 000s.
Display at 1/1 000.
Units of measurement: s, km / h, m / s, cm / s.
Height: 1 m.
Composition- 4 optical forks with digital display.
1 rail graduated from 0 to 900 mm.
1 base with screw for adjusting the verticality.
1 guide system for the release of the ball manually.
1 ball.
1 receptacle.

Superior Measurement Accuracy

Featuring a timer resolution of 0.01 seconds and an accuracy of 0.1 ms, this instrument ensures reliable and repeatable results. The photoelectric sensor enables precise detection of fall termination, and the electromagnet release system guarantees consistent sample dropping. It is ideally suited for both academic learning and professional laboratory research requiring meticulous measurement and analysis.

User-Friendly Design & Safety

The device is equipped with a digital buzzer indicator for the end of fall, intuitive digital display, and versatile operation modes (manual/automatic). The enclosed drop chamber and safety interlocks enhance user protection. Over-current protection and a sturdy powder-coated or polished finish guarantee both user safety and product longevity in laboratory settings.

Versatile Usage & Robust Construction

With a holding capacity ranging from 1 to 5 kg and compatibility with sample sizes to fit dimensions (500 x 300 x 500 mm), the instrument operates efficiently within ambient temperatures up to 50C and ambient humidity up to 80% RH. Its construction from premium materials including stainless steel assures durability, while the semi-automatic grade and digital readout streamline the workflow for users in research or industrial environments.

FAQs of Free Fall With Digital Displays:

Q: How does the Free Fall With Digital Displays measure the fall time of a sample?

A: The instrument uses a photoelectric sensor and an electromagnet release mechanism to detect and time the free fall event. Once the sample is released, the sensor measures the time interval and displays the result on a digital screen with a resolution of 0.01 seconds.

Q: What are the main benefits of using this free fall apparatus in a laboratory?

A: This equipment offers precise timing, reliable measurements with accuracy to 0.1 ms, and enhanced safety features, such as an enclosed drop chamber and over-current protection. Its robust construction ensures durability, and the digital buzzer provides immediate feedback at the end of the fall.

Q: When should I use the manual or automatic operating mode?

A: Manual mode is ideal for demonstrations or when you need manual control over each test, while automatic mode is suitable for repetitive experiments where consistency and efficiency are required. The choice depends on your experimental protocol and preferences.

Q: Where can this free fall equipment be used most effectively?

A: This instrument is designed for general laboratory environments, including educational institutions, research centers, and industrial quality control laboratories across India and internationally, thanks to its broad application and sturdy construction.

Q: What safety features are included in the device?

A: Safety features include an enclosed drop chamber to contain the sample, over-current protection to safeguard the electronics, and a safety interlock system to prevent accidental releases during operation, ensuring secure usage in laboratories.

Q: How does the digital buzzer alarm work in this apparatus?

A: The digital buzzer activates automatically at the end of each free fall measurement, signaling the user that the fall event has been completed and the data is available for recording or analysis.

Q: What is the process for setting up and operating this equipment?

A: After positioning the sample in the electromagnet holding system, select the desired operation mode. Initiate the free fall process, and the timer will start upon release. The photoelectric sensor detects the end of the fall, the time is recorded on the digital display, and the buzzer notifies you of completion.
