Flakiness Gauge

Flakiness Gauge

Send Inquiry

Request To Call Back

Flakiness Gauge

Get a Price/Quote

MOQ : 1 Piece

Flakiness Gauge Specification

Application
Aggregate Laboratory Tests

Humidity
Standard Laboratory Conditions

Resolution
1 mm

Accuracy
High, as per IS 2386 (Part I)

Automation Grade
Manual

Response Time
Instantaneous

Number of Specimens
Multiple, as per requirement

Specimen Size
Aggregate size 10 mm to 50 mm

Usage
Aggregate Laboratory Tests

Features
Corrosion resistant, Precision cut slots

Material
stainless steel

Max Height
50 mm

Hardness
Standard for stainless steel

Mounting Type
Handheld

Test Range
10 mm to 50 mm

Temperature
Room Temperature

Measuring Range
10 mm to 50 mm aggregate size

Product Type
Flakiness Gauge

Machine Weight
230 g

Test Speed
Manual

Test Width
Variable, up to 50 mm

Control Mode
Manual

Equipment Type
Flakiness Gauge

Finish
Polished and rust proof

Durability
Long lasting

Slot Dimensions
6 slots for different aggregate sizes (63 mm, 50 mm, 40 mm, 31.5 mm, 25 mm, 20 mm, 16 mm, 12.5 mm, 10 mm)

Flakiness Gauge Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Flakiness Gauge

Flakiness Gauge MTAT -08

It may be defined as the flakiness gauge of aggregates is the percentages by weight of particles whose least dimension is less than three fifths (0.6) of their mean dimension the test is not applicable to sizes smaller than 6.3 mm the apparatus consists of a stand and thickness gauge of sieve sizes 63,50,40,31.5,25,20,16,12.5,10 or 6.3 mm and a balance to weight the samples.

Features

Stainless Steel
Laser-etched markings clearly label each slot
Laser-cut heavy-gauge stainless steel for superior accuracy and service life
Corrosion resistance
Fine finish
Longer service life

Precision and Durability

Crafted from high-quality stainless steel, this Flakiness Gauge offers exceptional durability and a polished, corrosion-resistant finish. The precision-cut slots ensure accurate measurement across a broad aggregate size range, meeting rigorous industry standards. Its sturdy construction guarantees consistent performance, even with frequent laboratory usage.

Versatile Testing Capabilities

Equipped with eight slots supporting aggregate specimens from 10 mm to 50 mm, this gauge allows for simultaneous testing of various sizes, streamlining laboratory workflows. Its handheld, manual operation makes it adaptable for different testing requirements, bolstered by instant response and high resolution of 1 mm, suited for both routine and specialized aggregate analyses.

FAQs of Flakiness Gauge:

Q: How is the Flakiness Gauge used for testing aggregate samples?

A: The Flakiness Gauge is manually operated by passing aggregate pieces through its precision slots. Each piece is checked individually to determine if its thickness complies with the specified limits. This process helps in assessing the proportion of flaky particles as per IS 2386 (Part I) standards.

Q: What aggregate sizes can be tested with this Flakiness Gauge?

A: This gauge is designed to test aggregates ranging from 10 mm to 50 mm in size, using its 8 precision slots. The slots accommodate common laboratory requirements, making it suitable for a wide range of aggregate samples.

Q: When is the Flakiness Gauge typically used in laboratory procedures?

A: The Flakiness Gauge is primarily employed during routine aggregate quality assessments, especially when determining the suitability of aggregates for construction applications according to national standards.

Q: Where can this Flakiness Gauge be utilized effectively?

A: It is best suited for laboratory environments, including educational institutions, construction material testing labs, and commercial quality control facilities throughout India and abroad.

Q: What is the process for performing the flakiness index test using this equipment?

A: Aggregates are first separated by size, then each piece is passed through the designated slots. If an aggregate passes through a slot corresponding to its size range, it is considered flaky. The flakiness index is then calculated based on the proportion of flaky particles in the sample.

Q: How does using a stainless steel Flakiness Gauge benefit users?

A: Stainless steel construction ensures corrosion resistance, easy cleaning, and long-lasting accuracy. Combined with precision slots and a handheld format, it provides a reliable and user-friendly testing experience.

Q: What distinguishes this Flakiness Gauge in terms of accuracy and resolution?

A: It delivers high accuracy and a resolution of 1 mm, ensuring precise measurement for aggregate samples as specified by IS 2386 (Part I). This makes it suitable for stringent quality control testing.
