Crude Oil Distillation Setup

Price 100 INR/ Piece

Get a Price/Quote

MOQ : 1 , , Piece

Crude Oil Distillation Setup Specification

Test Range
Distillation Range for Crude Oil/Bitumen

Application
Bitumen Testing Instruments

Features
Corrosion-resistant, Heavy Base, Heat-resistant Glass, Easy Monitoring

Specimen Size
100 ml to 500 ml capacity flask

Humidity
Up to 85% RH (Non-Condensing)

Power Supply
230V AC, 50 Hz Single Phase

Hardness
Not Applicable (N/A)

Operating Voltage
230V AC

Measuring Range
0-100% (Volume Recovery)

Accuracy
1% on volume measurements

Gas Pressure
Atmospheric or as per requirement

Usage
Bitumen Testing Instruments

Number of Specimens
Single Test per Setup

Mounting Type
Bench Top

Product Type
Petroleum Distillation Apparatus

Frequency
50 Hz

Temperature
Room Temperature to 400C

Response Time
Instant on Thermometer

Equipment Type
Crude Oil Distillation Setup

Resolution
1 ml

Interface Type
Manual

Max Height
Approx. 600 mm

Port Size
Standard Glassware Joints, 24/29

Display Type
Temperature: Analog Dial Thermometer

Automation Grade
Manual

Capacity
Up to 500 ml

Machine Weight
Approx. 40 kg

Test Speed
Manual/Varies by setup

Control Mode
Manual

Crude Oil Distillation Setup Trade Information

Minimum Order Quantity
1 , , Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Crude Oil Distillation Setup

Petroleum Distillation Apparatus: MTBA-22

Technical Specification

The instrument consists of metal shield fitted with asbestos board to support distillation flask with GEARED height adjustable device.

It has slide for vapors tube and lining having glass window for Clear view of inside objects.

The condenser bath is provided with Mild Steel black painted stand (without glasswares) electrically operated on 220 volts AC mains.

Single Distillation Apparatus electrically heated with Energy Regulator with gear device

Single Distillation Apparatus with Energy Regulator and Temp. Indicator with gear device

A glass window is provided in front side for clear view of inside objects

Features

Electrically heated.
It also has cooling bath or condenser with M.S. black painted stand
The instrument is supplied with three square asbestos boards with 50mm and 70mm holes.(without glass wares)
It has a slot for vapors tube.
Geared height adjustable device.
The instrument consists of metal shield to support distillation flask
Complete with one 150 ml. flask, one 100 ml. crow receiver
Distillation apparatus as per method creosote oil and anthracite oil (without thermometer).

Accessories

Asbestos board

Robust Construction for Reliable Operation

Manufactured with heavy duty stainless steel and borosilicate glass, this distillation setup resists corrosion and withstands high thermal stress. Its powder coated frame adds further protection while blue accents ensure clear identification. The heat-resistant glass and splash shield enhance safety during operation, allowing repeated, consistent use in various industrial environments.

Versatile Heating and Safety Features

Whether using an electric heating mantle or an open flame, users benefit from both options depending on their laboratory requirements. Integrated thermal insulation and overheat protection minimize the risk of accidental exposure, while the instant-response analog thermometer allows immediate and accurate temperature monitoring from room temperature up to 360C.

Easy Installation and Compliance

The plug-and-play configuration allows immediate operation with minimal setup. The instrument adheres to IS 1448 (P:18) and ASTM D86 standards, ensuring test reliability. All glassware features standard 24/29 joints to simplify assembly and maintenance. The bench-top mounting and powder-coated finish complement compliance and practicality.

FAQs of Crude Oil Distillation Setup:

Q: How do I install the Crude Oil Distillation Setup for use in my laboratory?

A: The setup comes in a plug-and-play configuration, meaning it only needs to be placed on a stable bench and connected to a standard 230V AC power supply. All glassware is equipped with standard 24/29 joints for quick and secure assembly.

Q: What is the recommended process for conducting crude oil or bitumen distillation tests?

A: Prepare your sample (100 ml to 500 ml), assemble the included glassware, and select your heating method (electric mantle or open flame). You can manually control the test speed and monitor temperatures on the analog dial thermometer. Follow guidelines provided by IS 1448 (P:18) or ASTM D86 for optimal results.

Q: When should I use the splash shield and thermal insulation features?

A: The splash shield is required whenever you are actively heating samples to protect against accidental spills or splashes. Thermal insulation and overheat protection should always be engaged during operation, regardless of the heating method being used.

Q: Where is this equipment most suitable for use?

A: This setup is ideal for laboratory environments where bitumen or crude oil testing is required, such as industrial labs involved in petrochemical analysis or research institutes focused on material characterization.

Q: What safety protections are integrated into the distillation system?

A: The equipment includes a splash shield, thermal insulation, and an overheat protection mechanism. Heat-resistant glassware and a heavy-duty base add additional safety during high-temperature operations.

Q: How does the manual control mode benefit my testing workflow?

A: Manual control allows users to tailor the distillation process to specific sample requirements, giving flexibility in test speed and result accuracy. This is particularly helpful when working with varied types or sizes of specimens.

Q: What is the main benefit of choosing heavy duty stainless steel and borosilicate glass for material construction?

A: These materials offer superior corrosion resistance, long-term durability, and high thermal stability, which ensures accurate measurement and safety even under rigorous testing conditions.
