Computerised Pressure Measurement Bench

Computerised Pressure Measurement Bench

Send Inquiry

Request To Call Back

Computerised Pressure Measurement Bench

Get a Price/Quote

MOQ : 1 Piece

Computerised Pressure Measurement Bench Specification

Power Supply
220 V AC, 50 Hz

Resolution
0.01 bar

Accuracy
±0.25% F.S.

Specimen Size
Up to 200 mm length

Frequency
50 Hz

Display Type
Digital with software visualization

Application
Fluid Machines Equipments

Usage
Fluid Machines Equipments

Temperature
10°C - 40°C

Operating Voltage
220 V AC

Gas Pressure
0-10 bar

Response Time
<0.5 sec

Number of Specimens
Up to 2

Test Range
0-10 bar

Measuring Range
0-10 bar

Product Type
Computerised Pressure Measurement Bench

Max Height
900 mm

Mounting Type
Bench Top

Port Size
1/2 inch BSP

Automation Grade
Automatic

Humidity
30%-80% RH

Features
Real-time data acquisition, automatic test report generation, graphical analysis, multi-channel input

Hardness
Industrial-grade construction

Interface Type
USB/RS232

Capacity
10 bar

Machine Weight
Approx. 60 Kg

Test Speed
Variable, programmable

Test Width
400 mm

Test Stroke
0-250 mm

Control Mode
Computer Controlled (via dedicated software)

Data Storage
Internal and exportable to USB

Sensor Type
Precision pressure sensor, strain gauge type

Installation Requirement
Standard electrical outlet, stable surface

Maintenance
Low, annual calibration recommended

Safety Features
Overpressure protection, Emergency stop

Ambient Noise Level
<50 dB(A)

Material of Construction
Stainless Steel, Anodized Aluminium

Equipment Type
Computerised Pressure Measurement Bench

Software Compatibility
Windows 10/11

Calibration
Factory calibrated

Computerised Pressure Measurement Bench Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

About Computerised Pressure Measurement Bench

Computerised Pressure Measurement Bench

This computerised pressure measurement bench is a complete laboratory bench for test and calibration of the various elements of pressure readings as defined by new specifications for the industry. The unit is also an excellent test bench for all other disciplines which involve measuring and generating pressure. All pressure gauges are supplied with easy-to-read dial scales so that students are able to compare figures from documented records with how the pressure gauges are constructed in reality.

Precision Testing for Fluid Machines

Engineered for accurate pressure measurement in fluid machines, this bench uses a high-grade strain gauge sensor, delivering reliable data for up to two specimens simultaneously. The programmable test speed and real-time graphical analysis provide comprehensive insights into pressure behavior during testing.

User-Friendly Software and Connectivity

Control the measurement process using dedicated software designed for Windows 10/11. The intuitive interface allows easy test configuration, live monitoring, and automatic report generation, with seamless data export via USB or RS232, ensuring hassle-free integration into various laboratory workflows.

Robust Construction and Safety Features

Manufactured with stainless steel and anodized aluminium for lasting durability, the bench incorporates overpressure protection and an emergency stop, providing a safe testing environment. Its compact, bench-top design and low ambient noise make it suitable for laboratories and industrial settings.

FAQs of Computerised Pressure Measurement Bench:

Q: How do I install the Computerised Pressure Measurement Bench?

A: Installation requires a stable surface and access to a standard electrical outlet (220 V AC, 50 Hz). Place the unit securely on a bench top to ensure operator safety and accurate measurements.

Q: What types of pressure sensors are used in this equipment?

A: The bench utilizes a precision pressure sensor of strain gauge type, providing high accuracy (0.25% F.S.) and repeatable measurements within the 010 bar range.

Q: When is factory calibration required for this bench?

A: Factory calibration is performed prior to delivery. For best results, we recommend annual calibration to maintain optimal accuracy, though routine maintenance is minimal.

Q: Where can I use the pressure measurement bench?

A: Ideal for use in laboratories, educational institutions, research facilities, and industrial environments focused on fluid machines equipment testing and analysis.

Q: What is the process of acquiring and exporting test data?

A: During testing, data is acquired in real time with graphical visualization. Results and reports are automatically generated and can be stored internally or exported via USB or RS232 to external devices.

Q: How do the safety features enhance usage?

A: Safety is ensured by integrated overpressure protection, which safeguards the system and specimens, and an emergency stop function for immediate shutdown in case of operation anomalies.

Q: What are the benefits of computer-controlled testing on this bench?

A: Computer control enables precise, programmable test speeds and strokes, automatic report creation, graphical analysis, and multi-channel input, enhancing efficiency and data reliability for pressure testing applications.
