Centrifuge Extractor . Specification

Features
Removable Bowl, Solvent Resistant, Sturdy Construction

Application
Bitumen Testing Instruments

Humidity
Up to 90% RH

Power Supply
220 V AC, 50 Hz

Number of Specimens
1 per test

Mounting Type
Bench Top

Accuracy
±0.5%

Product Type
Centrifuge Extractor

Measuring Range
Up to 1500 gm

Equipment Type
Centrifuge Extractor

Max Height
350 mm

Operating Voltage
220 V AC

Usage
Bitumen Testing Instruments

Frequency
50 Hz

Response Time
Immediate

Temperature
5°C to 40°C

Automation Grade
Semi-Automatic

Specimen Size
1500 gm (Standard Sample Capacity)

Display Type
Analog

Capacity
1500 gm

Machine Weight
Approx. 35 kg

Test Speed
2800 rpm

Control Mode
Manual/Automatic

Safety Feature
Lid Interlock System

Bowl Material
Stainless Steel

Basket Speed Control
Variable

Finish Type
Powder Coated

Motor Type
High Speed Electric Motor

Noise Level
< 70 dB

Extraction Solvent
Trichloroethylene Recommended

Dimensions
Approx. 430 x 430 x 350 mm

Inner Chamber Material
Cast Iron

Centrifuge Extractor . Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces, , Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
carton box, export quality also available

Main Export Market(s)
Middle East, Asia, Africa

Main Domestic Market
All India

Certifications
ISO 9001, 14001 ,CE

Centrifuge Extractor . About

Centrifuge Extractor (Motorised)
Centrifuge Extractor (Motorised) For Testing Lab for Bitumen Testing Lab - Centrifuge Extractor (Motorised) for Bitumen Testing - Used for the determination of bitumen percentage in bituminous mixtures.

Used for the determination of bitumen percentage in bituminous mixtures. It consists of a removable, precision machined aluminium rotor bowl (accessory 1500 or 3000 g capacity), housed in a cylindrical aluminium box. The separate control panel incorporates an electronic card fitted with AC drive that automatically drives the bowl speed rotation ramp from 0 to 3600 R.P.M. as requested by Standards, with automatic fast stop bowl rotation at the end of the test. Supplied complete with speed regulator and digital display monitoring the frequency. Power supply: 230 V A.C. Single Phase.

Designed for Efficient Bitumen Extraction

Engineered for high-precision bitumen testing, the Centrifuge Extractor offers superior construction with a stainless steel bowl and cast iron chamber. Its high-speed electric motor and bench-top mounting maximize operational ease, making it an essential tool for laboratory analysis. The powder-coated finish ensures corrosion resistance and reliability during extensive usage.

Reliable Safety and Convenient Operation

Equipped with a lid interlock system, the Centrifuge Extractor prioritizes user safety by preventing accidental operation when the lid is open. The manual or automatic control options, analog display, and immediate response time streamline laboratory workflows, ensuring extraction processes are both reliable and efficient.

FAQs of Centrifuge Extractor .:

Q: How does the Centrifuge Extractor ensure operator safety during bitumen extraction?
A: The extractor features a safety lid interlock system, which prevents the machine from operating unless the lid is securely closed, safeguarding users from accidental contact with moving parts during operation.

Q: What materials are used for the bowl and inner chamber of the Centrifuge Extractor?
A: The bowl is constructed from stainless steel for durability and easy cleaning, while the inner chamber is made from sturdy cast iron, ensuring long-term reliability during repeated bitumen extraction processes.

Q: What is the recommended extraction solvent for bitumen testing with this equipment?
A: Trichloroethylene is the recommended extraction solvent, due to its compatibility with bitumen and the solvent-resistant design of the centrifuge components.

Q: Where can this Centrifuge Extractor be used effectively?
A: This equipment is ideal for laboratory environments focused on bitumen analysis, including research institutions, commercial laboratories, and quality control departments in India.

Q: What is the process for controlling basket speed and test operation?
A: The basket speed is variably adjustable, with control options available in both manual and automatic modes, allowing operators to tailor test conditions for optimal bitumen extraction results.

Q: What benefits does the removable bowl feature provide?
A: The removable bowl facilitates easy specimen loading, cleaning, and maintenance, enhancing both efficiency and hygiene in the laboratory.

Q: What is the extraction capacity and accuracy of the Centrifuge Extractor?
A: The machine accommodates standard specimen capacities up to 1500 gm, providing measurement accuracy within 0.5%, so users can rely on consistent and precise data during testing.
